30
Multi-System Wiring (Use SC-201-6M)
* The connector location may
be slightly different on the
actual circuit boards than in
these illustrations.
Unit 2
Units 3-6
Unit 1
Remote Controller Cord
Remote Controller Cord
Remote
Controller
Remote control
terminal block
No.6
90 90 89
102
PCB
Power
PCB
DPSW
12345678
B5 B5
System Controller
No.5
No.4
No.3
No.2
Remote Control
terminal block
Remote control
terminal block
System select connectors
Disconnect this
Connector
Disconnect this
Connector
Disconnect for system controller Disconnect for system controller
Disconnect this
Connector
Remote Controller Cord
PCB
Power
PCB
PCB
Power
PCB
Disconnect for system controller
* The remote controller terminal
location may differ depending
on the unit.
* Connect these to the
remote control terminal
block in each unit
To Next Page
