13
100 105 110 115 120 125 130 135 140 145 150 160 170
176
Shower, hot water
supply, etc.
Washing
dishes, etc.
High temperature
4
3
Turn on hot
water.
2
Set temperature.
Turn off the hot
water.
(
Always check the
)
temperature setting
before use.
Hot
Cold
Check the indicator lights.
Water temperature
On
Off
(°F
:
)
The temperature settings below are examples. The temperature setting
necessary depends on the usage, the length of piping and the time of year.
*Initial factory setting is 110°F
If fixtures incorporate mixing
valves, set the temperature
higher than usual.
* For most residential applications, the recommended setting temperature is 120°F or less.
For applications that occasionally require a higher temperature setting, locate the remote controller
in a convenient location (
p.61).
* Consult local codes for minimum operating temperatures.
Only N-069M
En069M/n063S(0113)J.p65 05.10.11, 10:56 PMPage 13 AdobePageMaker6.5J/PPC
