33
Hot-water feed route for N-069M only/Hot-water feed route for N-063S only
400 Heat exchanger & Exhaust box EHU-A SET-AS SKB7072 1<N-069M>
Heat exchanger & Exhaust box EHV-A SET-AS SKB7137 1<N-063S>
401 Thermal fuse fastener CZL CZLH005 1
402 Thermal fuse fastener DTJ DTJH002 5
403 Thermal fuse Q DTJ SET-V SBC7703 1
404 Remaining flame safety device 96 EHU EHUH001 1
407 Freeze preventive heater CRP SET-V SAQ7745 1
409 Heater fastener EHK EHKH001 1
410 Freeze preventive heater 3 BGD BGDH002 2
415 Quick fastener 13-22 SAD6537 2<N-069M>
Quick fastener 13-22 SAD6537 1<N-063S>
416 Quick fastener 16-25 SAD6593 2<N-069M>
Quick fastener 16-25 SAD6593 1<N-063S>
417 Quick fastener 16A 6340300 2
418 O-ring P12.5C 3359808 3<N-069M>
O-ring P12.5C 3359808 1<N-063S>
419 O-ring P16C 3223302 4<N-069M>
O-ring P16C 3223302 3<N-063S>
423 Thermostat BVU BVUH002 1
425 Water flow sensor set 3 DUV DUVD019 1
426 Water outlet magnetic sensor BWC BWCD090 1
427 Water inlet thermistor BWC BWCD097 1
429 Thermistor holding plate ALS ALSD088 2
430 Bypass pipe EHU EHUD005 1<N-069M>
431 Water valve set EHU EHUD007 1<N-069M>
432 Conduit 23 EHU EHUJ006 1<N-069M>
435 Water inlet fitting 20A set EHU EHUD001 1<N-069M>
Water inlet fitting 20A set EHV EHVD001 1<N-063S>
436 Water filter DTJ DTJD006 1
437 O-ring P16D FN7032 BRQL008 1
438 Water filter (SUS) EGB EGBD032 1
441 Water flow servo set HKP HKPD005 1<N-063S>
442 Water flow servo set2 DZT DZTD011 1<N-069M>
443 Heat exchanger thermister BWC BWCD098 1<N-069M>
444 O-ring P4C 1323709 2
445 Waterproof cover CZL CZLD041 1
446 Conduit 86 DZT DZTJ008 1
447 Hot-water thermistor BWC BWCD096 1<N-063S>
448 Hot-water outlet fitting 20A EHU EHUD004 1
451 Drain cock CRU CRUD003 1
452 Hot-water resistant O-ring P3 SAD6633 1
461 Cross recessed round-head P TIGHT screw 4X14
462 Cross & straight recessed truss type3 S TIGHT tapping screw 4X6
464 Cross recessed truss P TIGHT screw 4X10
465 Cross recessed round-head P TIGHT screw 4X14
466 Cross recessed round-head machine screw M4X8 <N-069M>
Part Nos. Part Names Order Nos. Q'ty/unit
En069M/n063S(2735)J.p65 05.12.13, 10:13 PM33
