Noritz N-084 - Page 29

56 57
XXXX. XX-XXXXXX
Top of heater
SERIAL NUMBER
Back of heater
Front of heater
Side of heater
Minimum Clearances from Combustible of Non-combustible Construction
Clearance
Made in JAPAN
XXXX XXXXXX
Type of Gas : Natural Gas
Max. Water Pressure : Min. 15psi ~ Max. 150 psi
Electrical Rating : AC 120 Volts 60 Hz
Manifold Gas Pressure : Min. 0.98 ~ Max. 2.3 inches
Inlet Gas Pressure : Min. 3.5 ~ Max. 10.5 inches
Recovery Rate : 313 Gallons/Hour
BTU Input : Max. 236,000 ~ Min. 21,000
Model : N-084
Tel : (949)420-0409
20492 Crescent Bay Dr.Ste.104.Lake Forest CA 92630
NORITZ AMERICA CORPORATION
Automatic Instantaneous Water Heater
REQUIRED CLEARANCES TO COMBUSTIBLES
ANSI Z21.10.3 2000
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliances
Outdoor Install Indoor Install
36 inches
1 inch
24 inches
6 inches 2 inches
4 inches
1 inch
12 inches
