Procedure Diagram
3. Removegasvalveassembly

(1) Locate“C”clamponthebottomright
handcorneroftheunitthatattaches
thegasconnectiontothemanifold
plateandremove.
(2) Locateinletgaspipetomanifoldand
pushup.
(3) Locatethelargewiringconnection,
thatattachesthewiresfromthe
manifoldplatetothewiringharness,
anddisconnecttheplug.
(4) Nextlocatethefourbigsilverscrews
holdingthemanifoldplatetothe
burner,therewillbetwoontheright
andleftsideofthemanifoldplate.
Removethosefourscrewsandthe
manifoldplateandpipecanbe
removedandsetaside.
 





4. Unplugallwiresthatattachtothewiring
harnessandthebodyofthewaterheater

(1) Wiringforthefan











