Noritz NRC111DV - General Parts -2; Remote Controller (RC-7651 M)

10
RemoteController(RC-7651M)
For setting the hot
water temperature,
the ow meter alarm,
and other settings.
PowerOn/OffButton
For turning the
heater on and off.
Flow Meter Alarm Set Button
For setting the ow
meter alarm.
( p.14-15)
Setting Buttons
* Before use, remove the protective sheet from the remote controller surface.
Temperature Setting
(Ex.:110°F)
Flow Meter Setting
The display will ash
after hitting the ow
meter alarm set button.
( p.15)
Error Code
When this indicator is lit,
the hot water temperature
can be set. ( p.12)
Whatisactuallydisplayeddependsonhowthewaterheaterisset.
A number will ash if
a failure occurs.
( p.28)
PriorityIndicator
Burner On Indicator
When burning, the
indicator is lit.
( p.13and15)
Note: As shipped from the factory, the remote controller is set to display in °F and gallons.
To adjust the display to °C and liters, refer to the Installation Manual.
General Parts -2
