Nortech PD130 - PD132 Enhanced Detector - Order Number 301 FT0101; PD134 Enhanced Detector - Order Number 301 FT0122

301UM0030_01 PD130 Enhanced Vehicle Detector User Manual Page: 19 of 29
6.2 PD132 Enhanced Detector - Order number 301FT0101
11-pin connector wiring for PD132 DETECTOR - Order number 301FT0101
301FT0041
Wiring Harness
Wire COLOUR
11 PIN
Connector
Pin No.
FUNCTION
Red 1 Live Power supply
230V 10% 50/60 Hz
Black 2 Neutral
Grey 3 Pulse Relay N/O
Violet 4 Pulse Relay Common
Yellow 5 Presence Relay N/O
Brown 6 Presence Relay Common
Blue 7 Loop Twist this
Pair
Blue 8 Loop
Green/Yellow 9 Earth
Pink 10 Presence Relay N/C
White 11 Pulse Relay N/C
WARNING: 11. The wiring harness wire colour to PIN No.
assignment only applies to wiring harness Part
No. 301FT0041. Other wiring harnesses will have
different wire colour to PIN No. assignments.
6.3 PD134 Enhanced Detector - Order number 301FT0122
11-pin connector wiring for PD134 DETECTOR - Order number 301FT0122
301FT0041 Wiring
Harness Wire
COLOUR
11 PIN
Connector
Pin No.
FUNCTION
Red 1 Live Power supply
12V –10% to 24V +10%
AC/DC
Black 2 Neutral
Grey 3 Pulse Relay N/O
Violet 4 Pulse Relay Common
Yellow 5 Presence Relay N/O
Brown 6 Presence Relay Common
Blue 7 Loop Twist this
Pair
Blue 8 Loop
Green/Yellow 9 Earth
Pink 10 Presence Relay N/C
White 11 Pulse Relay N/C
WARNING: 12. The wiring harness wire colour to PIN No.
assignment only applies to wiring harness Part
No. 301FT0041. Other wiring harnesses will have
different wire colour to PIN No. assignments.
