POWER SUPPLY DETAILS:
Nominal Voltage: _______ V Minimum Voltage: _______ V Maximum Voltage: ________ V
AC or DC ? ______________ If AC then the Frequency _______ Hz
LOOP DETAILS
Size of loop: ___ m by ___ m Shape of loop: _________________________________
Number of Turns: _____
Size of wire used (mm
2
or AWG) _____________
Type of wire insulation and thickness of insulation:_____________
How far below the surface is the loop: __________ mm
Are there any metal objects below the loop such as concrete reinforcing, water pipes etc if yes please give
details:
_____________________________________________________________________________
____________________________________________________________________________
_____________________________________________________________________________
Are there any power cables below the loop if yes please give details:
_____________________________________________________________________________
_____________________________________________________________________________
_____________________________________________________________________________
Are there any other loops in the area if so how many? ________ and how close to this loop are they?
________ m
FEEDER CABLE DETAILS
Length of feeder cable ______________m
Size of wire used (cross sectional area of copper mm
2
or AWG) _____________ (should be 1.5 mm
2
or
larger)
Type of wire insulation and thickness of insulation:_____________ (should be __________ )
Type of feeder cable used (screened, armoured, multicore, etc.)
____________________________________________________________________________________
____________________________________________________________________________________
In the feeder cable how many twists per meter are there?____________ (should be more than 20 per metre)
