6.5 Cable specification
1. Single phase unit
Nameplate
maximum
current
Phase line Earth line MCB Creepage protector Signal line
Nameplate
maximum
current
Phase line Earth line MCB Creepage protector Signal line
No more than 10A
10~16 A
16~25 A
25~32 A
32~40 A
40 ~63 A
63~75 A
75~101 A
101~123 A
123~148 A
148~186 A
186~224 A
2×1,5 mm
2
2×2,5 mm
2
2×4 mm
2
2×6 mm
2
2×10 mm
2
2×16 mm
2
2×25 mm
2
2×25 mm
2
2×35 mm
2
2×50 mm
2
2×70 mm
2
2×95 mm
2
1,5 mm
2
2,5 mm
2
4 mm
2
6 mm
2
10 mm
2
16 mm
2
25 mm
2
25 mm
2
35 mm
2
50 mm
2
70 mm
2
95 mm
2
20 A
32 A
40 A
40 A
63 A
80 A
100 A
125 A
160 A
225 A
250 A
280 A
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1
sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
30mA less than 0.1 sec
n×0.5mm
2
No more than 10A
10~16 A
16~25 A
25~32 A
32~40 A
40 ~63 A
63~75 A
75~101 A
101~123 A
123~148 A
148~186 A
186~224 A
3×1,5 mm
2
3×2,5 mm
2
3×4 mm
2
3×6 mm
2
3×10 mm
2
3×16 mm
2
3×25 mm
2
3×25 mm
2
3×35 mm
2
3×50 mm
2
3×70 mm
2
3×95 mm
2
1,5 mm
2
2,5 mm
2
4 mm
2
6 mm
2
10 mm
2
16 mm
2
25 mm
2
25 mm
2
35 mm
2
50 mm
2
70 mm
2
95 mm
2
20 A
32 A
40 A
40 A
63 A
80 A
100 A
125 A
160 A
225 A
250 A
280 A
n×0.5mm
2
2. Three phase unit
When the unit will be installed at outdoor, please use the cable which can against UV.
