Component List – 4065 – Rev S.1
ITEM
PART#
DESCRIPTION
QTY
ITEM
PART#
DESCRIPTION
QTY
1
39115
9hp Honda Engine
1
45
406520
Outrigger Pin
4
2
3007
Coupling, 1”
1
46
37877
Pin, 1.5 x 9.25, greasable
1
3
3009
Coupling Insert
1
47
406515
Side-Side Travel Pin
1
4
3002
Coupling, 1/2”
1
48
40652
Outrigger
2
5
779683
Pump Mounting Bracket
1
49
406501
Trencher Frame
1
6
10564
3 GPM Hydraulic Gear Pump
1
50
50SOR101
2
#10 ORB x 3/4” FPT
Fitting
1
7
50E86
#8 ORB x #6 JIC Elbow
1
51
5023
3/4” MPT x 3/4” HB Fitting
2
8
777342
24” Hydraulic Hose Assembly
1
52
17141
3/4” Hose Clamp
2
9
5087
29” Hydraulic Hose Assembly
1
53
505121
3/4” Clear Vinyl Hose
2
10
777343
47” Hydraulic Hose Assembly
1
54
4020
Filter, 20 GPM
1
11
777357
43” Hydraulic Hose Assembly
2
55
50SN121
3/4” MPT Nipple
1
12
5389
#8 ORB x #8 JIC Fitting
1
56
50SE12
3/4” NPT Street Elbow
1
13
37660
84” Hydraulic Hose Assembly
1
57
5390
#8 JIC x 1/2” HB Fitting
1
14
777344
69” Hydraulic Hose Assembly
1
58
777119
1/2” Hose Clamp
2
15
37661
133” Hydraulic Hose
Assembly
1
59
2264
1/2” Bulk Hose
2
16
777356
116” Hydraulic Hose
Assembly
1
60
5013
3/4” MPT x 1/2” HB Fitting
1
17
5019
#8 ORB x #6 JIC Fitting
8
61
4011
Suction Strainer
1
18
5OR10
6
#10 ORB x #6 JIC Fitting
1
62
12412
Lug Bolt
8
19
201616
Hydraulic Control Inlet
1
63
780201
Wheel/Tire 16.5x6.5x8
2
20
30149
Hydraulic Control Valve
2
64
124A
Dust Cap
2
21
30150
Hyd. Control Valve w/ Relief
2
65
82140
1/8” x 2” Cotter Pin
17
22
201617
Hydraulic Control Outlet
1
66
12559
1” Spindle Nut
2
23
201526
Valve Mounting Kit
1
67
124292
Bearing
4
24
5018
1/2 MPT x #6 JIC Elbow
7
68
124294
4 Bolt Hub w/ Race
2
25
788105
3” x 12” Tie Rod Cylinder
4
69
124293
Seal
2
26
406519
Pin, 1x5
1
70
12422
Pair of Torsion Axles
1
27
406518
Pin, 1x3.25
5
71
38587
Coupler 3500#
1
28
31257
3/4” SAE O-ring x 1/2” FPT
8
72
1130
Safety Chain
2
30
406510
Pin, 1x8
5
73
777346
Right Leg
1
34
37878
Pin, 1x6
2
74
40659
Left Leg
1
35
5026
#8 ORB x #6 JIC Flow
Reducer
1
75
1744
Seat
1
36
37836
Bucket
1
76
4066
Sight Gauge
1
37
37835
Bucket Link
1
77
784456
Hydraulic Dip Stick
1
38
37863
Right Link
1
78
5024
3/8 MPT x #6 JIC Fitting
1
39
37834
Left Link
1
79
5025
3/8 MPT x 1/2 MPT
Nipple
1
40
37833
Arm
1
80
5027
1/2” NPT Steel Street
Elbow
1
41
406513
Pin, 1.5x6.7, greasable
2
82
30313
.177 Bridge Pin
7
42
777277
Boom
1
83
37543
Warning/Operating
Decals
1
44
37818
Pivot Assembly
1
84
779681
Guard insert for 779683
2
