Norton Commando 961 - Torque Table Chassis

18
Torque table Chassis
Description
Component
Torq
ue
Remarks
N-m
Sprocket cover
SPROCKET COVER TO C/CASE
BOLT, CAP HD, M8 X 30 X 1.25
20
Front wheel
SPINDLE FOR CONVENTIONAL FORKS
SPINDLE, FRONT WHEEL
60
SPINDLE FOR USD FORKS
SPINDLE, FRONT WHEEL, USD FORKS,
HIGH BARS
60
Rear wheel
TO CLAMP SPROCKET TO CARRIER
LOCKNUT, FLANGED, M10 X 1.25
55
SPINDLE NUT
LOCKNUT, THIN, M24 X 2
110
Brakes
HALF CLAMP BOLTS
BOLT, M6 X 25 X 1.0, FLANGED, CP
HD,GOLD
8
BRAKE SYSTEM ONLY
BOLT, BANJO, M10 x 1.0 x 30, CHROME
25
BRAKE SYSTEM ONLY
BOLT, BANJO, M10 x 1.0 x 18, CHROME
25
BRACKET TO MASTER CYLINDER (remote)
BOLT, CAP HD, M6 X 12 X 1.0
6
LEFT HAND CALIPER BRACKET TO FORK (axial)
BOLT, CAP HD, M10x20x1.25
35
CALIPER TO BRACKET, BRACKET TO FORK
(axial)
BOLT, CAP HD, M10x30x1.25
35
6 PER SIDE, PATCH LOCKED (axial)
BOLT, BUTTON HD, INT HEX, M8 X 16
25
6 PER SIDE, PATCH LOCKED (radial)
BOLT, BUTTON HD, INT HEX, M8 X 20
25
TO CLAMP CALIPER TO FORK (radial)
BOLT, CALIPER, RADIAL
35
TO CLAMP REAR MASTER CYLINDER +
BRACKET + HEEL GUARD TO HANGER
BOLT, CAP HD, M6 X 20
10
TO CLAMP RESERVOIR TO BRACKET
BOLT, CAP HD, M6 x 10
8
BRAKE SYSTEM ONLY
BOLT, BANJO, M10x1.0x18, CHROME
25
CLAMP P CLIP TO SWINGARM
BOLT, CAP HD, M5 X 15 X 0.8
7
REAR CALIPER TO CARRIER
BOLT, CAP HD, M8 X 20 X 1.25
28
DISK, PATCHLOCKED
BOLT, BUTTON HEAD, INT HEX, M10X20
43
