Norton Commando 961 - Page 20

20
Description
Component
Torque
Remarks
N-m
Oil cooler
TO CLAMP OIL COOLER TO FRAME
BOLT, CAP HD, M6 X 20 x 1.0
6
Airbox and Exhaust
TO AIR FILTER CLAMP
BOLT, BUTTON HD, M5x12
4
TO CLAMP TRANSITION PIECE
BOLT, CAP HD, M6 X 20
8
TO HEAD
LOCKNUT, FLANGED, M8 X 1.25
19
2 REQUIRED FOR HOMOLOGATION
LAMBDA SENSOR, EXHAUST, M10 X
1.25
25
USED TO CLAMP EXHAUST SECTIONS
EXHAUST CLAMPS
10
Bodywork
TO BOLT HUGGER
BOLT, CAP HEAD, M5 X 15 X 0.8
7
Fuel tank
FUEL PUMP
BOLT, CAP HD, M5 X 12 X 0.8
9
MOULDED TANK TO FRAME
BOLT, CAP HD, M6 X 16 X 1.0
9
Electrical system
FOR ROLLOVER SWITCH
BOLT, CAP HD, M4 X 25 X 0.7
3
MOUNTED ON LOWER YOKE
BOLT, BUTTON HD, INT HEX, M8 X 16
18
TO CLAMP IGNITION COIL PACK
BOLT, CAP HD, M6 X 40 X 1.0
10
PANEL TO YOKE FIXING
BOLT, CAP HD, M8 X 20 X 1.25
20
Lighting
TO CLAMP NUMBER PLATE LIGHT
BOLT, CAP HEAD, M5 X 15 X 0.8
7
