Nova Florida Pictor Dual

Questions and Answers

M
Morgan SalinasAug 4, 2025
What to do if my Nova Florida Boiler has shut down and red light no. 4 is flashing?
- A
  Andrew HarrellAug 4, 2025
  If your Nova Florida boiler has shut down and red light no. 4 is flashing, the issue could stem from: * A faulty flue pressure switch: Check the flue pressure switch and replace if necessary. * Disconnected or faulty silicone pipes: Reconnect or replace the silicone pipes. * Insufficient air intake or flue gas discharge: Check, unclog or replace the air/flue gas ducts as needed. * A faulty fan: Replace the fan. * A faulty PCB: Replace the PCB. * Clogged air/flue system: Check the flue gas exhaust and air intake vent grilles in the boiler room. * A faulty flue gas thermostat: Replace the flue gas thermostat.
J
Joy MeyerAug 9, 2025
What to do if my Nova Florida Boiler is not providing DHW?
- Q
  qgarciaAug 9, 2025
  If your Nova Florida boiler isn't providing domestic hot water (DHW), consider the following: * System insufficient pressure or capacity: Check DHW system. * Check DHW flow metre filter. * Disconnected or faulty flow metre sensor: Reconnect or replace it. * Flow metre is stuck: Replace it.
J
Jeffrey DoyleAug 13, 2025
What to do if my Nova Florida Boiler has shut down and red light no. 3 is flashing?
- J
  Julie FoleyAug 13, 2025
  If your Nova Florida boiler has shut down and red light no. 3 is flashing, it might be due to: * Clogged pipes, shut thermostatic valves, or closed system stopcocks: Check the CH system. * A stuck or faulty pump: Check the pump.
M
Marissa DavisAug 17, 2025
What to do if my Nova Florida Boiler has shut down and red light no. 6 is flashing?
- C
  Cassandra ScottAug 17, 2025
  If your Nova Florida boiler has shut down and red light no. 6 is flashing, consider the following: * Possible water leaks: Check the system for leaks. * Disconnected pressure switch: Reconnect it. * Faulty water pressure switch: Replace it.
J
Jennifer ButlerAug 21, 2025
What to do if my Nova Florida Boiler has shut down, red light no. 2 and green light no. 8 are flashing?
- M
  Michael AndersonAug 22, 2025
  If your Nova Florida boiler has shut down, and red light no. 2 and green light no. 8 are flashing, it could be due to: * Disconnected CH probe: Reconnect it. * Faulty CH probe: Replace it.
A
Alison EspinozaAug 26, 2025
What to do if my Nova Florida Boiler has shut down and red light no. 2 is flashing?
- J
  Joseph FullerAug 26, 2025
  If your Nova Florida boiler has shut down and red light no. 2 is flashing, it could indicate: * Disconnected DHW probe: Reconnect it. * Faulty DHW probe: Replace it.
C
Curtis WallaceOct 30, 2025
What to do if my Nova Florida Boiler has shut down and red light no. 5 is flashing?
- C
  Curtis HunterOct 30, 2025
  If your Nova Florida boiler has shut down and red light no. 5 is flashing, it could be due to several reasons: * Gas supply failure: Check the gas pressure and the gas network safety valve. * Disconnected gas valve: Reconnect the gas valve. * Faulty gas valve: Replace the gas valve. * Faulty PCB: Replace the PCB. * Faulty spark electrode: Replace the spark electrode. * Faulty ignition transformer: Replace the ignition transformer. * Incorrect neutral and phase connections: Verify correct neutral and phase connections. * Disconnected or faulty flame detection electrode wire: Connect or replace the flame detection electrode wire. * Faulty detection electrode: Replace the electrode. * PCB not detecting flame: Replace the PCB. * P ACC Ignition value set point is too low:...

Summary

General Information and Safety

Manual Overview and Liability

Details the manual's importance, manufacturer liability for installation errors, and user responsibilities.

Installation and Maintenance Guidelines

Covers boiler installation compliance, integrity checks, approved accessories, packaging, and routine maintenance.

Critical Safety Warnings

Includes procedures for boiler failure, inactivity, freezing, gas leaks, and country of installation compliance.

User Instructions

Control Panel Functions

Explains the indicators and controls on the boiler's front panel for user operation.

Boiler Operation and Modes

Covers starting, normal operation, DHW priority, anti-freezing, and external probe adjustments.

Boiler Shut-down and Maintenance

Details shutdown causes, indicator lights, maintenance responsibilities, and user notes.

Technical Specifications

Boiler Characteristics and Dimensions

Lists construction, operating characteristics, and physical dimensions of the boiler models.

Connection Layouts and Operating Data

Illustrates hydraulic/gas connections and presents operating data, consumption, and general characteristics.

General Characteristics

Details electrical specifications, consumption, maximum temperatures, and system capacities for various boiler models.

Installation Procedures

Installation Standards and Location

Specifies installation compliance, suitable locations, and positioning guidelines using templates.

Boiler Mounting and Ventilation

Covers boiler mounting, room ventilation requirements, and general flue connection principles.

Flue System and Duct Configurations

Details flue system requirements and various air/flue duct configurations for different boiler types.

Boiler Efficiency Testing

Explains how to use the "chimney sweep" function and perform combustion checks.

Connections, System Loading, and Adjustment

Gas and Power Connections

Covers gas mains connection, pipe sizing, leak tests, and electrical power supply requirements.

Plumbing and Control Connections

Details plumbing, by-pass, thermostat, and external probe connections for system integration.

System Loading and Boiler Activation

Covers system filling, air bleeding, pre-start checks, and the procedure for starting the boiler.

Testing, Maintenance, and Troubleshooting

Boiler Testing and Maintenance

Outlines preliminary checks before testing, routine maintenance schedule, and cleaning procedures.

Troubleshooting Guide

A table diagnosing common boiler malfunctions, their probable causes, and recommended solutions.
