Nova CAMBRIDGE NOV-CD-4005B

ASSEMBLY INSTRUCTIONS
WINDGUARD ASSEMBLY
16 17
STEP 1
Loosen all the grub-screws in the connectors with a Phillips screwdriver (not
supplied). Loosely position each windguard panel, one at a time, using the top and
bottom connectors until a rectangular windguard is formed. Do not tighten any
screws until the windguard is formed.
M
N
L
L1
M
x4
N L L1
x4 x2 x2
