Novoferm HAD MS - Operating Instructions Continued; Impulse OPEN;impulse CLOSE; Radio hand transmitter (optional); Maintenance and Checks

position or the door can be stopped beforehand by
pressing button . If button is pressed again, the
door continues to open. The door is closed by dead
man's control, i.e. pressing button and keeping it
pressed, until the door reaches its CLOSE end-of-
travel position. If the button is released during
closing, the door stops instantly.
By briefly pressing button or generating an impulse
from an external impulse generator the door starts to
open until reaching the OPEN end-of-travel position,
or the door can be stopped beforehand by pressing
button . By briefly pressing button the door starts
closing until reaching the CLOSE end-of-travel
position.
This operating option demands that a safety edge
(menu 35) be installed. If the safety edge is triggered
during closing, the door stops and changes direction.
If the safety edge is triggered during opening, this has
no effect. In the case of a defect, the door can be
closed using .
Button: Start
The operator starts up and causes the door to travel
to the set OPEN or CLOSE travel limits.
Door stops.
Door continues to travel but in the opposite direction.
Button: Light
The light function involves a continuous light that can
be switched on/off independent of the door action.
Impulse OPEN / impulse CLOSE
Radio hand transmitter (optional)
First impulse:
Impulse generated during travel:
A new impulse is generated:
Maintenance / Checks
Servicedisplay
If the control unit establishes the need for testing /
inspection, "service" shows up in the display. Contact
a specialist company.
Foryourownsafety,werecommend
thatpriortoinitialoperationand
wheneverrequired-howeveratleast
onceayear,youhavethedoorsystem
andthedocklevellertestedbya
specialistcompany.
