- Seatpost clamp
Headset: The FUZZ frame comes with a tapered head tube with 1.5 ZS (bottom: 56mm ID* / top: 44mm ID) and 115mm
stack height. It fits forks with standard 1-1/8” steerer tubes. Don’t cut your steer-tube too low! The process of mounting
headset in the frame should be done by a qualified mechanic.
*Please note that headsets with OD55 mm bottom cups or other internal headsets won’t fit. Only headsets with a bottom
cup with 56mm OD will work with the FUZZ frame. The use of a wrong type of headset can be dangerous & can damage
the frame
Seatpost & seatpost clamp: The FUZZ frame works with 30.9mm seatposts and 34.9mm seatpost clamps. Do not extend the
seatpost above the minimum insertion mark. Maximum seat insertion is 175mm for S and M size and 185mm for L size.
