Vibratory plate compactors Operation manual
*performance of engine HONDA,SUBARU is according to SAE J1349
*performance of engine BRIGGS&STRATTON is according to SAE J1940
2.2. Lubricants
For use in both engine and the vibrator use high-quality engine oils of the following specifications:
10W-30 API CJ-4+/CI-4/CF/SM,
- engine oil HONDA GX120 capacity 0,60 l
- engine oil HONDA GX160 capacity 0,60 l
- engine oil BRIGGS&STRATTON 750 SERIES capacity 0,54-0,59 l
- engine oil SUBARU EX17 capacity 0,60 l
- oil in the vibrator capacity 0,07 l ± 5%
2.3. Machine identification
It is highly important to refer the exact type and serial number of your machine whenever contacting the
manufacturer or the dealer (i.e. for warranty reasons, ordering of spare parts or service, for technical
questions). These data are stated at the type plate.
Fig. Location of type plate Fig. Example of type plate
