3
＜List of H group functions＞
Ｈ№
Name & Set range
（Initial value is underlined）
Change
during
driving
Record
of set
value
H00
Selection of functions of IN1 input
0:Driving with High input
1:Driving with Low input (reverse)
2:Separate IN1 (reverse) from
driving condition
3:Separate IN1 from driving condition
4:Control P1 with IN1 (reverse)
5:Control P1 with IN1
6:
Use IN1 as ON delay timer 1 input
and use IN2 as OFF delay timer 1
input
7:
Use IN1 (reverse) as ON delay
timer 1 input and use IN2 as OFF
delay timer 1 input
Can
H01
ON delay timer 1
0.0
~60.0 (Sec.)
Can
H02
OFF delay timer 1
0.0
~30.0(Sec.)
Can
H03
Selection of functions of IN2 input
Selection of functions of IN1 input
0:Timer 2 operates with Low input
1: Timer 2 operates with High input
2: Operate timer 2 with IN1 input,
and output the result on P2
3: Operate timer 2 with reverse
signal of IN1 input, and output
the result on P2
4: Control timer 2 with IN1 input,
and output the result on P2.
Use timer 2 as one shot timer.
Can
H04
ON delay timer 2
0.0
~60.0(Sec.)
Can
H05
OFF delay timer 2
0.0
~30.0(sec.)
Can
H06
Soft start time
0.0~5.0(Sec.) Initial value 0.5
Can
H07
Soft stop time
0.0~5.0(Sec.) Initial value 0.3
Can
H08
Use of work shortage timer
0: Not used
1:Detected by IN1 signal
2:Detected by IN2 signal
Can
H09
Work shortage detection time
1.0~120.0(Sec.)
Initial value 10.0
Can
＊Initial set value. Figure in () is the initial set value of ECJ45.
Note) Unchangeable functions during driving become changeable at the stopping state of controller (When external control
terminal is at stopping side or panel control, press STOP key). Select panel control [2] with selection J02 of driving method
when it is difficult to cut off the external control. Then controller stops.
Ｈ№
Name & Set range
（Initial value is underlined）
Change
during
driving
Record
of set
value
H10
Work shortage reset time
0.1~30.0(Sec.)
Initial value 1.0
Can
H11
Multi speed input switching
0:Switching with signals of B1 and
B2 terminals
1:Control speed with A1 input
Can
not
H12
Frequency of speed 1
30.0~500.0(Hz)
Initial value 140.0
(70.0)
*
Can
H13
Voltage of speed 1
0~200(V)
Initial value 100
Can
H14
Frequency of speed 2
30.0~500.0(Hz)
Initial value 140.0
(70.0)
*
Can
H15
Voltage of speed 2
0~200(V)
Initial value 100
Can
H16
Frequency of speed 3
30.0~500.0(Hz)
Initial value 140.0
(70.0)
*
Can
H17
Voltage of speed 3
0~200(V)
Initial value 100
Can
H18
% speed of speed 1
0~100(%)
Initial value 50
Can
H19
% speed of speed 2
0~100(%)
Initial value 50
Can
H20
% speed of speed 3
0~100(%)
Initial value 50
Can
H21
Resonance frequency data
30.0~500.0(Hz)
Initial value 140.0
(70.0)
*
Can
not
H22
Setting of gain
0~200
Initial value 150
Can
H23
Setting of MAX. % speed
30~100(%)
Initial value 70
Can
not
H24
Setting of stability
-90~0~+90
Initial value -27
Can
H25
Scaling
40~100
Can
