REPLACEMENT PARTS LIST

(SMOKE6 & SMOKE13)

Reference # Description Replacement Part #

ELECTRICAL COMPONENTS:

1 Power Terminal Block ...................................................................................... 50–1332

2 Ground Lug ........................................................................................................ 50–1329

3 Control Fuse Assembly.......................................................................................66-1097

4 Contactor:

120v coil....................................................................................................66-2013

240v coil....................................................................................................66-2017

5 Heating Element:

ES-6, 208v, 1000w................................................................................60-0194-A

ES-6, 240v, 1000w................................................................................60-0195-A

ES-13, 208v, 2000w..............................................................................60-0192-A

ES-13, 240v, 2000w..............................................................................60-0193-A

6 Internal Smoke Box Element Assembly...........................................................251-4002

External Smoke Box Element ...........................................................................66-4038

7 Motor Assy w/Blower Wheel...........................................................................250-1035

8 Smoke Box Intensity Control .............................................................................66-1172

9 Buzzer Alarm ......................................................................................................66-1113

10 Water Solenoid Valve:

120v coil................................................................................................ 50-0308-1

240v coil................................................................................................ 50-0307-1

11 Repeat Cycle Timer:

120v...........................................................................................................66-8012

240v...........................................................................................................66-8065

12 Relay (DPDT, 20 amp):

120v...........................................................................................................50-0433

240v...........................................................................................................66-9025

13 Cooling Fan Assembly (4"):

120v.........................................................................................................250-3001

240v.............................................................................................................. 97525

14 Thermal Overload Safety (425F) ......................................................................66-1114

INTERIOR COMPONENTS

15 Side Rack:

6-Pan................................................................................................... 101-7013-A

7-Pan................................................................................................... 101-7013-A

16 Shelf ……………………………………………………………………..101-0025

17 Water Injection Nozzle (AUTOMIST option)...................................................31-0033

18 Internal Smoker Chip Box ..................................................................................47-9290

External Smoker Chip Box ................................................................................47-9286
