Numark iCDMIX 2 Service Manual

NC10 BOM
3.03.LM1117.18R SMT IC LM1117-1.8 SOT-223 ±2％ PCS 1 U112
3.03.TCC8600.00R SMT IC TCC8600 SQFP14X14-128(N) PCS 1 U101
3.03.M1742.00R SMT IC PCM1742E SSO16 BB PCS 1 U108
3.03.39VF800.00R SMT IC SST39VF800A TSOP-48 PCS 1 U105
3.03.HY57V.00R SMT IC HY57V281620 TSOP54 PCS 1 U104
3.03.BU9543.00R SMT IC BU9543KV VQFP64 ROHM PCS 1 U114
3.03.AIC809.00R
SMT IC AIC809-31PU SOT-23 AIC PCS 1 U102
3.09.A.12MHZR Crystal Oscillator 12MHz X2-49S PCS 1 X102
3.09.A.16M9344R Crystal Oscillator 16.9344MHz X2-49S PCS 1 X103
3.50.01.16P.HOR Connector 1.0*16P PCS 1 J102
3.50.02.05P.H0R Connector 2.0*5P PCS 1 J201
3.50.02.06P.H0R Connector 2.0*6P PCS 1 J104
3.50.03.03P.H0R Connector 2.54*3P PCS 1 J203
3.50.03.04P.H0R Connector 2.54*4P PCS 1 J202
3.61.A.06P150.F28R Wiring 6P*150MM 28# PCS 1 J201
3.61.A.05P200.T28R Wiring 5P*200MM 28# PCS 1 J104
3.57.A.03P150.H28R Wiring 3P*150MM 28＃ PCS 1 AV100
3.59.B.03P320.F26R Wiring 3P*320MM 26# PCS 1 J203
3.55.T.16P150.100R Wiring 16P*150mm 1.0 PCS 1 J102
3.59.A.08P100.H26R Wiring 8P*100MM 26＃ PCS 1 JK2001
3.59.B.05P280.H22R Wiring 5P*280MM 22＃ PCS 1 J103
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.009CR Decoder Board® NC10-14 PCB-09C 138×92mm ! PCS 1
R217 R227 R196 R248 R250 R252 R300 R301
R296 R297 R219 R218 BD120 BD121 BD113 BD115
R175 R174 R173
3.25.05.0004R70JR SMT Resistor 4R7 0805 ±5％ PCS 2 R225 R224
3.25.05.0010R00JR SMT Resistor 10R 0805 ±5％ PCS 2 R243 R244
3.25.06.0018R00JR SMT Resistor 18R 1206 ±5％ PCS 1 R241
3.25.05.0047R00JR SMT Resistor 47R 0805 ±5％ PCS 3 R290 R291 R302
3.25.05.0091R00JR SMT Resistor 91R 0805 ±5％ PCS 1 R281
3.25.05.0100R00JR SMT Resistor 100R 0805 ±5％ PCS 7 R198 R200 R237 R239 R197 R199 R202
3.25.05.0470R00JR SMT Resistor 470R 0805 ±5％ PCS 1 R254
SMT Resistor 560R 0805 ±5％ PCS 2 R242 R245
3.25.05.K001R00JR SMT Resistor 1K 0805 ±5％ PCS 3 R253 R263 R264
3.25.05.K001R20JR SMT Resistor 1K2 0805 ±5％ PCS 2 R282 R283
3.25.05.K002R20JR SMT Resistor 2K2 0805 ±5％ PCS 1 R256
3.25.05.K007R50JR SMT Resistor 7K5 0805 ±5％ PCS 1 R261
3.25.05.K003R30JR SMT Resistor 3K3 0805 ±5％ PCS 3 R260 R284 R285
SMT Resistor R100 R101 R167 R164 R170 R172 R201 R169
SMT Resistor R231 R265 R163 R166 R206 R168
SMT Resistor R195 R203 R204 R205 R208 R209 R213 R257
SMT Resistor R216 R247 R249 R251 R262 R230 R258
3.25.05.K015R00JR SMT Resistor 15K 0805 ±5％ PCS 2 R238 R240
3.25.05.K022R00JR SMT Resistor 22K 0805 ±5％ PCS 8 R286 R287 R288 R289 R220 R221 R222 R223
3.25.05.K033R00JR SMT Resistor 33K 0805 ±5％ PCS 2 R218 R219
3.25.05.K027R00JR SMT Resistor 27K 0805 ±5％ PCS 1 R255
3.25.05.K047R00JR SMT Resistor 47K 0805 ±5％ PCS 4 R207 R268 R269 R102
3.25.05.K100R00JR SMT Resistor 100K 0805 ±5％ PCS 1 R226
3.25.05.K012R00JR SMT Resistor 12K 0805 ±5％ PCS 1 R259
3.25.05.0000R00JR SMT Resistor 0R 0805 ±5％ PCS 2 R235 R236
3.25.05.M001R00JR SMT Resistor 1M 0805 ±5％ PCS 1 R228
3.25.05.K003R90JR SMT Resistor 3K9 0805 ±5％ PCS 2 R292 R293
3.25.05.M006R20JR SMT Resistor 6M2 0805 ±5％ PCS 2 R193 R194
3.25.05.K006R80JR SMT Resistor 6K8 0805 ±5％ PCS 2 R294 R295
3.26.05.01.22P0JFR SMT Capacitor 22pF/50V 0805 ±5％ PCS 6 C175 C178 C187 C188 C193 C194
3.26.05.01.27P0JFR SMT Capacitor 27pF/50V
0805 ±5％ PCS 2 C173 C174
3.26.05.02.101JFR SMT Capacitor 101/50V 0805 ±5％ PCS 4 C250 C251 C248 C249
3.26.05.02.391JFR SMT Capacitor 390pF/50V 0805 ±5％ PCS 1 C176
3.26.05.02.681JFR SMT Capacitor 680pF/50V 0805 ±5％ PCS 1 C183
3.26.05.03.102KFR SMT Capacitor 102/50V 0805 ±10％ PCS 2 C246 C247
3.26.05.03.122KFR SMT Capacitor 122/50V 0805 ±10％ PCS 1 C177
3.26.05.03.272KFR SMT Capacitor 272/50V 0805 ±10％ PCS 1 C181
3.26.05.03.332KFR SMT Capacitor 332/50V 0805 ±10％ PCS 2 C244 C243
3.26.05.03.822KFR SMT Capacitor 822/50V 0805 ±10％ PCS 1 C182
3.26.05.04.103MFR SMT Capacitor 103/50V 0805 ±20％ PCS 2 C241 C242
SMT Capacitor C100 C115 C116 C180 C197 C200 C201 C198
SMT Capacitor C117 C119 C122 C123 C151 C152 C153 C199
SMT Capacitor C154 C155 C156 C157 C158 C159 C160 C202
SMT Capacitor C161 C162 C163 C165 C166 C167 C169 C226
SMT Capacitor C186 C195 C171 C179 C170
C252
3.26.05.05.224MDR SMT Capacitor 224/25V 0805 ±20％ PCS 1 C196
3.26.05.06.105MDR SMT Capacitor 105/25V 0805 ±20％ PCS 6 C172 C189 C190 C191 C231 C232
SMT Capacitor BD108 BD109 BD117 BD110 BD111 BD114 BD118 BD116
SMT Capacitor BD105 BD106 BD107
Position
PCS 14
FR-4 dual-layer
19
104/50V 0805 ±20％
13PCS1.5K@100MHz 0805 ±5％
PCS
SMT Resistor 0R 0805 ±5％ PCS
10K 0805 ±5％
4K7 0805 ±5％
3.11.06.1D5K.05R
3.25.05.0000R00JR
3.26.05.05.104MFR
3.25.05.K004R70JR
3.25.05.K010R00JR 15
38PCS
拟制： 校对： 审核： 日期：12/16/2009 第2页，共8页
