Numark iCDMIX 2 Service Manual

NC10 BOM
ERP Code Part name Specification Unit
Q'ty
3.01.NC10.009CR Decoder board (L) NC10-14 PCB-09C 138×92mm PCS 1
R217 R227 R196 R248 R250 R252 R300 R301
R296 R297 R219 R218 BD120 BD121 BD113 BD115
R175 R174 R173
3.25.05.0004R70JR SMT Resistor 4R7 0805 ±5％ PCS 2 R225 R224
3.25.05.0010R00JR SMT Resistor 10R 0805 ±5％ PCS 2 R243 R244
3.25.06.0018R00JR SMT Resistor 18R 1206 ±5％ PCS 1 R241
3.25.05.0047R00JR SMT Resistor 47R 0805 ±5％ PCS 3 R290 R291 R302
3.25.05.0091R00JR SMT Resistor 91R 0805 ±5％ PCS 1 R281
3.25.05.0100R00JR SMT Resistor 100R 0805 ±5％ PCS 7 R198 R200 R237 R239 R197 R199 R202
3.25.05.0470R00JR SMT Resistor 470R 0805 ±5％ PCS 1 R254
SMT Resistor 560R 0805 ±5％ PCS 2 R242 R245
3.25.05.K001R00JR SMT Resistor 1K 0805 ±5％ PCS 3 R253 R263 R264
3.25.05.K001R20JR SMT Resistor 1K2 0805 ±5％ PCS 2 R282 R283
3.25.05.K002R20JR SMT Resistor 2K2 0805 ±5％ PCS 1 R256
3.25.05.K007R50JR SMT Resistor 7K5 0805 ±5％ PCS 1 R261
3.25.05.K003R30JR SMT Resistor 3K3 0805 ±5％ PCS 3 R260 R284 R285
SMT Resistor R100 R101 R167 R164 R170 R172 R201 R169
SMT Resistor R231 R265 R163 R166 R206 R168
SMT Resistor R195 R203 R204 R205 R208 R209 R213 R257
SMT Resistor R216 R247 R249 R251 R262 R230 R258
3.25.05.K015R00JR SMT Resistor 15K 0805 ±5％ PCS 2 R238 R240
3.25.05.K022R00JR SMT Resistor 22K 0805 ±5％ PCS 8 R286 R287 R288 R289 R220 R221 R222 R223
3.25.05.K033R00JR SMT Resistor 33K 0805 ±5％ PCS 2 R218 R219
3.25.05.K027R00JR SMT Resistor 27K 0805 ±5％ PCS 1 R255
3.25.05.K047R00JR SMT Resistor 47K 0805 ±5％ PCS 4 R207 R268 R269 R102
3.25.05.K100R00JR SMT Resistor 100K 0805 ±5％ PCS 1 R226
3.25.05.K012R00JR SMT Resistor 12K 0805 ±5％ PCS 1 R259
3.25.05.M001R00JR SMT Resistor 1M 0805 ±5％ PCS 1 R228
3.25.05.K003R90JR SMT Resistor 3K9 0805 ±5％ PCS 2 R292 R293
3.25.05.M006R20JR SMT Resistor 6M2 0805 ±5％ PCS 2 R193 R194
3.25.05.K006R80JR SMT Resistor 6K8 0805 ±5％ PCS 2 R294 R295
3.26.05.01.22P0JFR SMT Resistor 22pF/50V 0805 ±5％ PCS 6 C175 C178 C187 C188 C193 C194
3.26.05.01.27P0JFR SMT Capacitor 27pF/50V 0805 ±5％ PCS 2 C173 C174
3.26.05.02.101JFR SMT Capacitor 101/50V 0805 ±5％ PCS 4 C250 C251 C248 C249
3.26.05.02.391JFR SMT Capacitor 390pF/50V 0805 ±5％ PCS 1 C176
3.26.05.02.681JFR SMT Capacitor 680pF/50V 0805 ±5％ PCS 1 C183
3.26.05.03.102KFR SMT Capacitor 102/50V 0805 ±10％ PCS 2 C246 C247
3.26.05.03.122KFR SMT Capacitor 122/50V 0805 ±10％ PCS 1 C177
3.26.05.03.272KFR SMT Capacitor 272/50V 0805 ±10％ PCS 1 C181
3.26.05.03.332KFR SMT Capacitor 332/50V 0805 ±10％ PCS 2 C244 C243
3.26.05.03.822KFR SMT Capacitor 822/50V 0805 ±10％ PCS 1 C182
3.26.05.04.103MFR SMT Capacitor 103/50V 0805 ±20％ PCS 2 C241 C242
SMT Capacitor C100 C115 C116 C180 C197 C200 C201 C198
SMT Capacitor C117 C119 C122 C123 C151 C152 C153 C199
SMT Capacitor C154 C155 C156 C157 C158 C159 C160 C202
SMT Capacitor C161 C162 C163 C165 C166 C167 C169 C226
SMT Capacitor C186 C195 C171 C179 C170 C252
3.26.05.05.224MDR SMT Capacitor 224/25V 0805 ±20％ PCS 1 C196
3.26.05.06.105MDR SMT Capacitor 105/25V 0805 ±20％ PCS 6 C172 C189 C190 C191 C231 C232
SMT Capacitor BD108 BD109 BD117 BD110 BD111 BD114 BD118 BD116
SMT Capacitor BD105 BD106 BD107
3.11.06.01UH.10R SMT Capacitor 1UH 1210 ±10％ PCS 1 U109
3.23.05.222B.W1020R Electrolytic Capacitor 2200uF/10V Φ10×20mm +80%-20% 85℃ PCS 2 C230 C234
3.23.04.100C.W0511R Electrolytic Capacitor 100uF/16V Φ5×11mm +80%-20% 85℃ PCS 7 C211 C212 C233 C215 C218 C219 C220
3.23.03.10UC.W0511R Electrolytic Capacitor 10UF/16V Φ5×11 +80%-20% 85℃ PCS 4 C237 C238 C239 C240
3.23.02.3U3F.W0511R Electrolytic Capacitor 3.3UF/50V Φ5×11 +80%-20% 85℃ PCS 1 C216
3.23.03.22UC.W0511R Electrolytic Capacitor 22uF/16V Φ5×11 +80%-20% 85℃
PCS 1 C228
3.23.03.47UC.W0511R Electrolytic Capacitor 47uF/16V Φ5×11 +80%-20% 85℃ PCS 2 C221 C222
3.23.04.470B.WAA11R Electrolytic Capacitor 470U/10V Φ6.3×11 +80%-20% 85℃ PCS 1 C227
3.23.04.470C.W0812R Electrolytic Capacitor 470U/16V Φ8×12 +80%-20% 85℃ PCS 3 C217 C235 C236
3.03.BA5968.00R SMT IC BA5968 HSOP28_ROHM PCS 1 U113
3.08.01.4148W05R SMT Diode 1N4148 LL-34 1206 PCS 3 D103 D104 D106
3.11.03.001UH.00R Bead Inductor 1UH 3.5*6 PCS 3 BD119 BD200 BD202
3.25.0A.0000R01JR SMT Array Resistor 0R ML08W1 ±5％ PCS 1 RA105
3.25.0A.0033R00JR SMT Array Resistor 33R ML08W1 ±5％ PCS 1 RA104
RA200 RA201 RA202 RA203 RA204 RA206 RA207 RA208
RA209
3.25.0A.K001R00JR SMT Array Resistor 1K ML08W1 ±5％ PCS 1 RA103
3.05.2SA1576R SMT Transistor 2SA1576 SOT-23 PCS 1 Q107
3.05.DTC114R SMT Transistor DTC114TUA SOT-323 PCS 1 Q108
3.05.S8050R SMT Transistor S8050 SOT-23 PCS 1 Q109
3.02.BA033T.00R DIP IC BA033T TO-220 ±2％ PCS 1 U111
3.02.KA7805.00R DIP IC KA7805 TO-220 ±2％ PCS 1 U110
3.03.24C02D.00R SMT IC 24C02D SO-8 PCS 1 U100
3.03.M4558.00R SMT IC NJM4558 DMP8 JRC PCS 1 U115
Position
PCS
4K7 0805 ±5％
FR-4 dual-layer
PCS
15
PCS 19
14
10K 0805 ±5％
38PCS104/50V 0805 ±20％3.26.05.05.104MFR
3.25.0A.0100R00JR
3.11.06.1D5K.05R
3.25.05.K004R70JR
3.25.05.K010R00JR
PCS
SMT Array Resistor 100R ML08W1 ±5％
3.25.05.0000R00JR SMT Resistor 0R 0805 ±5％
1.5K@100MHz 0805 ±5％ 13
9PCS
拟制： 校对： 审核： 日期：12/16/2009 第1页，共8页
