NC10 BOM
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.003DR PCB NC10-PCB-03D 123×428mm PCS 1 94VO
3.25.05.0000R00JR SMT Resistor 0Ω 0805 ±5％ PCS 2 RJ404 RJ202
3.25.05.0100R00JR SMT Resistor 100Ω 0805 ±5％ PCS 6 R211 R213 R311 R313 R411 R413
R643 R644 R101 R210 R212 R310 R312 R410
R647 R648 R649 R650 R651 R681 R682 R683
R686 R687 R688 R689 R690 R691 R692 R693
R412 R646 R684 R685 R694
3.25.05.K001R20JR SMT Resistor 1K2 0805 ±5％ PCS 4 R559 R562 R610 R611
3.25.05.K001R80JR SMT Resistor 1K8 0805 ±5％ PCS 2 R561 R560
3.25.05.K002R20JR SMT Resistor 2K2 0805 ±5％ PCS 4 R443 R442 R343 R342
3.12.A8.K002R40JR Carbon Film Resistor 2K4 1/8W ±5％ PCS 2 R563 R566
3.12.A8.K002R70JR Carbon Film Resistor 2K7 1/8W ±5％ PCS 2 R564 R565
3.25.05.K003R90JR SMT Resistor 3K9 0805 ±5％ PCS 4 R676 R605 R616 R618
R206 R208 R215 R216 R217 R306 R308 R315
R406 R408 R414 R416 R417 R415 R100 R316
R317
3.25.05.K005R60JR SMT Resistor 5K6 0805 ±5％ PCS 2 R103 R104
3.25.05.K006R20JR SMT Resistor 6K2 0805 ±5％ PCS 4 R558 R557 R556 R555
R428 R427 R424 R423 R328 R327 R324 R323
R224 R223 R228 R227
R106 R105 R111 R125 R129 R222 R225 R229
R322 R325 R329 R330 R331 R422 R425 R429
R619 R621 R242 R243 R622 R623 R230 R231
R430 R431
3.25.05.K012R00JR SMT Resistor 12K 0805 ±5％ PCS 2 R613 R612
3.25.05.K015R00JR SMT Resistor 15K 0805 ±5％ PCS 4 R697 R679 R698 R699
R141 R140 R238 R239 R240 R241 R338 R339
R438 R439 R440 R441 R905 R906 R340 R341
3.25.05.K024R00JR SMT Resistor 24K 0805 ±5％ PCS 2 R615 R614
3.25.05.K027R00JR SMT Resistor 27K 0805 ±5％ PCS 2 R908 R909
3.25.05.K047R00JR SMT Resistor 47K 0805 ±5％ PCS 7 R142 R102 R546 R407 R309 R209 R545
3.25.05.K056R00JR SMT Resistor 56K 0805 ±5％ PCS 8 R236 R237 R336 R337 R436 R437 R608 R609
3.25.05.K100R00JR SMT Resistor 100K 0805 ±5％ PCS 2 R914 R915
3.25.05.K180R00JR SMT Resistor 180K 0805 ±5％ PCS 2 R696 R674
3.25.06.0000R00JR SMT Resistor 0R 1206 ±5％ PCS 8 RJ101 RJ301 RJ201 RJ8 RJ403 RJ403 RJ4 RJ405
R218 R220 R318 R319 R320 R321 R418 R419
R219 R221 R420 R421
3.25.06.K004R70JR SMT Resistor 4K7 1206 ±5% PCS 2 R314 R214
3.25.06.K010R00JR SMT Resistor 10K 1206 ±5% PCS 3 R326 R426 R226
3.25.06.K047R00JR SMT Resistor 47K 1206 ±5% PCS 3 R409 R307 R207
3.12.A8.0010R00JR Carbon Film Resistor 10R 1/8W ±5% PCS 2 R913 R912
R521 R633 R403 R600 R601 R910 R606 RR601
R112 R114 R400 R401 R402 R526 R527 R200
R203 R204 R300 R301 R302 R404 R405 R205
R305 R607 R602 R603 R911 R525 R109 R108
R201 R202 R303 R304
3.12.A8.K002R20JR Carbon Film Resistor 2K2 1/8W ±5% PCS 3 R465 R265 R365
3.12.A8.K004R70JR Carbon Film Resistor 4K7 1/8W ±5% PCS 2 R927 R926
3.12.A8.K006R40JR Carbon Film Resistor 6K4 1/8W ±5% PCS 2 R678 R677
3.12.A8.K010R00JR Carbon Film Resistor 10K 1/8W ±5% PCS 2 R617 R620
3.12.A8.K015R00JR Carbon Film Resistor 15K 1/8W ±5% PCS 6 R432 R433 R232 R233 R332 R333
3.12.A8.K022R00JR Carbon Film Resistor 22K 1/8W ±5% PCS 6 R902 R901 R907 R904 R900 R903
3.26.05.01.10P0JFR SMT Capacitor 10P/50V 0805 ±5％ PCS 6 C206 C207 C306 C307 C406 C407
3.26.05.01.47P0JFR SMT Capacitor 47P/50V 0805 ±5％ PCS 4 C102 C910 C605 C604
3.26.05.02.101JFR SMT Capacitor 101/50V 0805 ±5％ PCS 7 C549 C550 C900 C624 C625 C551 C552
3.26.05.02.221KFR SMT Capacitor 221/50V 0805 ±10％ PCS 1 C112
3.26.05.02.471KFR SMT Capacitor 471/50V
0805 ±10％ PCS 2 C626 C627
3.22.12.222JG05R Polyester Film Capacitor 222/63V 7625C ±5％ 5MM PCS 6 C313 C312 C213 C212 C412 C413
3.22.12.472JG05R Polyester Film Capacitor 472/63V 7625C ±5％ 5mm PCS 1 C103
3.22.12.682JG05R Polyester Film Capacitor 682/63V 7625C ±5％ 5MM PCS 6 C415 C414 C315 C314 C215 C214
3.22.13.153JG05R Polyester Film Capacitor 153/63V 7625C ±5％ 5MM PCS 6 C420 C418 C320 C318 C220 C218
3.22.13.223JG05R Polyester Film Capacitor 223/63V 7625C ±5％ 5MM PCS 6 C216 C217 C417 C416 C317 C316
3.22.13.393JG05R Polyester Film Capacitor 393/63V 7625C ±5％ 5MM PCS 2 C104 C105
3.23.02.1U0F.X0407R Electrolytic Capacitor 1UF/50V Φ4×7 +80%-20% 105℃ PCS 2 C639 C638
3.23.03.10UC.X0407R Electrolytic Capacitor 10uF/16V Φ4×7 +80%-20% 105℃ PCS 8 C531 C532 C632 C633 C634 C635 C636 C637
C425 C424 C325 C324 C225 C224 C100 C101
C210 C222 C223 C308 C309 C310 C311 C322
C409 C410 C411 C422 C423 C528 C535 C905
C907 C613 C614 C211 C209 C208 C906 C903
C122 C123 C323 C408
C109 C108 C106 C107 C200 C201 C202 C203
C300 C301 C302 C303 C304 C305 C400 C401
C404 C405 C541 C542 C543 C544 C600 C601
C901 C912 C913 C619 C620 C621 C622 C602
Carbon Film Resistor3.12.A8.0100R00JR
Electrolytic Capacitor3.23.03.22UC.X0407R
Electrolytic Capacitor
Position
PCS 12
3.25.05.K004R70JR
29PCS1K 0805 ±5％SMT Resistor3.25.05.K001R00JR
3.25.05.K008R20JR SMT Resistor
PCS
38PCS
36
26PCS
PCS
PCS 12
16
36PCS
SMT Resistor 2K2 1206 ±5%
3.23.03.47UC.X0407R
3.25.06.K002R20JR
3.25.05.K022R00JR
3.25.05.K010R00JR
100R 1/8W ±5%
4K7 0805 ±5％
8K2 0805 ±5％
10K 0805 ±5％SMT Resistor
SMT Resistor 22K 0805 ±5％
17PCSSMT Resistor
22uF/16V Φ4×7 +80%-20% 105℃
47uF/16V Φ4×7 +80%-20% 105℃
拟制： 校对： 审核： 日期：12/16/2009 第4页，共8页
To Next Page
