Numark iCDMIX 2 Service Manual

NC10 BOM
C204 C205 C402 C403 C603 C902
3.52.06.005R Wiring 5mm Φ0.6 PCS 5 J107 J213 J214 J218 J739
3.52.06.006R Wiring 6mm Φ0.6 PCS 2 R642 R641
J634 J633 J632 J536 J549 J553 J106 J203
J308 J317 J319 J321 J305 J303 J209 J208
J430 J411 J104 J219 J212 J537 J541 J215
J601 J726 J736 J547 J207 J210 J206 J429
J216 J217
J532 J530 J531 J224 J439 J438 J440 J428
J412 J538 J527 J508 J600 J526 J737 J738
J417 J331 J332 J554 J415
3.52.06.012R Wiring 12mm Φ0.6 PCS 8 J539 J337 J322 J202 J304 J402 J525 J552
J433 J443 J444 J431 J545 J105 J316 J211
J204 J205 J416 J323 J442 J413 J535 J414
J318 J320
3.52.06.018R Wiring 18mm Φ0.6 PCS 3 J434 J436 J435
3.52.06.020R Wiring 20mm Φ0.6 PCS 2 J605 J507
3.02.JRC4556.00R DIP IC JRC4556AD DIP8 JRC PCS 1 IC900
IC901 IC100 IC102 IC201 IC202 IC300 IC301 IC302
IC501 IC502 IC600 IC601 IC604 IC605 IC401 IC200
IC400 IC402
3.02.KA2284.00R DIP IC KA2284 SIP9 PCS 4 IC609 IC608 IC607 IC606
3.07.3R4SD.39R LED 3R4SD-3(039) PCS 3 LD401 LD301 LD201
3.07.2R54SD.06R LED red 2R54SD-06 LED2*5 PCS 8 LD619 LD618 LD617 LD616 LD615 LD614 LD613 LD612
LD611 LD610 LD609 LD608 LD607 LD606 LD605 LD604
LD601 LD600 LD603 LD602
3.31.01.22E09LR On-Off PS-22E09L-GP PCS 3 SW401 SW301 SW201
3.31.04.SL020315PAR Slide Switch SL10020F-0203-15PA-SN PCS 1 SW200
3.31.04.SL020215PAR Slide Switch SL10020F-0202-15PA-SN PCS 5 SW802 SW400 SW300 SW100 SW600
3.32.03.1601G.025R Knob Potentiometer RB1601GOEOB-HAI-025 50K PCS 2 VR603 VR900
3.32.03.1601G.120R Knob Potentiometer RB1601GOE0B-HAI-120 C50K×2 PCS 1 VR901
3.32.03.1601N.001R Knob Potentiometer RB1601NOEOB-HAI-001 10K PCS 1 VR100
3.32.03.1601N.038R Knob Potentiometer RB1601NOEOB-HAI-038 50K PCS 2 VR101 VR102
3.32.03.1601G.121R Knob Potentiometer RB1601GOE0B-HAI-121 B10K×2 PCS 3 W400 W300 W200
W403 W402 W401 W303 W302 W301 W203 W202
W201
3.32.02.4505G.003R Slide Potentiometer SC4505GOA0X-HAI-003 A50K*2 PCS 4 VR200 VR300 VR400 VR606
3.59.B.03P060.H26R Wiring 3P*60MM 2.54 26＃ PCS 1 CN901A
3.61.A.04P100.H28R Wiring 4P*100MM 2.0 28# PCS 1 FC19
3.59.A.05P220.H26R Wiring 5P*220MM 2.0 26＃ PCS 2 CN299A CN399A
3.59.A.05P180.H26R Wiring 5P*180MM 2.0 26# PCS 1 FC201
3.59.A.06P200.H26R Wiring 6P*200MM 2.0 26＃ PCS 1 CN199A
3.59.B.08P250.H26R Wiring 8P*250MM 2.54 26＃ PCS 1 CN602A
3.57.B.03P100.H28R Shielding Wire 3P*100MM 2.54 28＃ PCS 1 CN18A
3.57.B.05P100.H28R Shielding Wire 5P*100MM 2.54 28＃ PCS 1 CN21A
3.57.A.06P450.H28R Shielding Wire 6P*450MM 2.0 28＃ PCS 1 CN500A
3.57.A.03P400.C28R Shielding Wire 3P*400MM 2.0 28＃ PCS 1 FC102 FC102A
3.57.A.03P350.C28R Shielding Wire 3P*350MM 2.0 28＃ PCS 2 FC202 FC202A FC302 FC302A
3.57.A.03P150.C28R Shielding Wire 3P*150MM 2.0 28＃ PCS 1 FC402 FC402A
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.006BR PCB NC10-PCB-06B 20×74mm PCS 1 94VO
3.32.02.4501F.002R Slide Potentiometer SB4501FOAOX-HAI-002 100K PCS 1 VR600
3.50.03.05P.W0R Connector 5P*2.54 PCS 1 CN21B
3.50.03.03P.W0R Connector 3P*2.54 PCS 1 CN18B
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.004DR Output PCB NC10-PCB-04D 263×53mm PCS 1 94VO
3.25.05.0000R00JR SMT Resistor 0R 0805 ±5％ PCS 2 R630 R629
3.25.05.0010R00JR SMT Resistor 10R 0805 ±5％ PCS 1 R575
3.25.05.0100R00JR SMT Resistor 100R 0805 ±5％ PCS 4 R517 R518 R522 R528
3.25.05.0470R00JR SMT Resistor 470Ω 0805 ±5％ PCS 8 R594 R593 R592 R591 R538 R537 R536 R533
3.25.05.K001R00JR SMT Resistor 1K 0805 ±5％ PCS 3 R588 R576 R587
3.25.05.K004R70JR SMT Resistor 4K7 0805 ±5％ PCS 4 R570 R569 R568 R567
3.25.05.K010R00JR SMT Resistor 10K 0805 ±5％ PCS 8 R579 R580 R585 R586 R627 R628 R631 R632
3.25.05.K012R00JR SMT Resistor 12K 0805 ±5％ PCS 2 R597 R595
3.25.05.K022R00JR SMT Resistor 22K 0805 ±5％ PCS 4 R544 R543 R542 R541
3.25.05.K039R00JR SMT Resistor 39K 0805 ±5％ PCS 2 R590 R589
R624 R604 R659 R658 R657 R656 R655 R654
R515 R514 R513 R511 R510 R509 R508 R507
R653 R516
3.25.05.K100R00JR SMT Resistor 100K 0805 ±5％ PCS 4 R584 R583 R582 R581
3.25.05.K270R00JR SMT Resistor 270K 0805 ±5％ PCS 4 R550 R549 R548 R547
3.25.05.M002R20JR SMT Resistor 2.2M 0805 ±5％ PCS 1 R577
3.25.06.0100R00JR SMT Resistor 100R 1206 ±5％ PCS 1 R625
Wiring
18PCS
Wiring
SMT Resistor
SMT IC PCS 18
34
Position
Position
Wiring
PCS
PCS
3.52.06.010R
3.52.06.075R PCS
3.52.06.015R 15mm Φ0.6
green 2G54HD-06 LED2*5
NJM4558M DMP8 JRC
47K 0805 ±5％
3.07.2G54HD.06R
3.03.M4558.00R
21
18PCS
PCS
12
9RB1601GOE0B-HA1-018 B100KKnob Potentiometer
3.25.05.K047R00JR
3.32.03.1601G.018R
LED
7.5mm Φ0.6
10mm Φ0.6
