Numark iCDMIX 2 Service Manual

NC10 BOM
3.25.06.K560R00JR SMT Resistor 560K 1206 ±5％ PCS 1 R512
3.12.A8.0047R00JR Carbon Film Resistor 47R 1/8W ±5% PCS 4 R500 R501 R502 R599
R529 R532 R519 R520 R523 R524 R530 R531
R626
3.12.A8.0220R00JR Carbon Film Resistor 220R 1/8W ±5% PCS 4 R574 R573 R572 R571
3.12.A8.K001R00JR Carbon Film Resistor 1K 1/8W ±5% PCS 2 R503 R504
3.12.A8.K012R00JR Carbon Film Resistor 12K 1/8W ±5% PCS 2 R598 R596
3.26.05.02.101JFR SMT Capacitor 101/50V 0805 ±5％ PCS 4 C504 C505 C506 C507
C563 C564 C565 C566 C567 C568 C580 C581
C557 C558 C559 C560 C561 C562 C553 C554
3.22.12.332JG05R Polyester Film Capacitor 332/63V 7625C ±5％ 5mm PCS 4 C519 C518 C517 C516
3.22.13.123JG05R Polyester Film Capacitor 123/63V 7625C ±5％ 5MM PCS 4 C527 C526 C525 C524
3.23.02.4U7C.W0407R Electrolytic Capacitor 4.7uF/16V Φ4×7 +80%-20%85℃ PCS 1 C575
3.23.03.10UC.W0407R Electrolytic Capacitor 10uF/16V Φ4×7 +80%-20% 85℃ PCS 6 C533 C534 C608 C609 C610 C611
C500 C501 C502 C503 C509 C514 C529 C530
C571 C572 C573 C574 C513 C515 C569 C570
C548 C520 C521 C522 C523 C545 C546 C547
C578 C579 C606 C607 C576 C577
3.23.05.102C.W1016R Electrolytic Capacitor 1000uF/16V Φ10×16 +80%-20% 85℃ PCS 1 C536
3.52.06.005R Wiring 5mm Φ0.6 PCS 1 J718
J722 J724 J727 J725 J735 J734 J733 J729
J720
3.52.06.010R Wiring 10mm Φ0.6 PCS 6 J732 J731 J730 J740 J741 J742
3.52.06.015R Wiring 15mm Φ0.6 PCS 3 J728 J719 J717
3.08.01.4148W05R SMT Diode IN4148 LL-34 PCS 2 D501 D500
3.05.1015R SMT Transistor A1015 SOT-23 PCS 1 Q504
3.04.C2878R DIP Transistor C2878 TO-92 PCS 4 Q503 Q502 Q501 Q500
3.03.JRC2068.00R SMT IC NJM2068 DMP8 JRC PCS 4 IC507 IC505 IC503 IC500
3.03.M4558.00R SMT IC NJM4558M DMP8 JRC PCS 3 IC504 IC506 IC602
3.31.04.22H09G6R Slide Switch SK22H09G6 PCS 2 S501 S500
3.30.01.CK63521PS3R MIC CK-6.35-21（PJ-617AG-02-EP） 3P PCS 1 MIC500
3.30.01.CT0207P00R MIC CT/PJ-02-07 PCS 1 MIC501
3.30.01.CT305MP00R Output CT3-05M PCS 2 J501 J502
3.29.RCA209A.01R Socket AV2-8.4-9 PCS 1 AV501
3.29.RCA410A.01R Socket AV4-8.4-10 PCS 2 J500 AV500
3.50.02.03P.H0R Connector 3P*2.0 PCS 2 J111B J110B
3.50.02.05P.H0R Connector 5P*2.0 PCS 2 CN299B CN399B
3.50.02.06P.H0R Connector 6P*2.0 PCS 2 CN199B CN500B
3.50.03.07P.H0R Connector 7P*2.54 PCS 1 CN603B
3.50.03.08P.H0R Connector 8P*2.54 PCS 1 CN602B
3.50.02.08P.H0R Connector 8P*2.0 PCS 2 DIN1004D DIN1004C
3.54.20.100.B00R Grounding 100MM 20＃ Φ4 PCS 1
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.0005R MIC PCB NC10&14 PCB-05 35×35mm PCS 1 94VO
3.12.A4.0033R00JR Carbon Film Resistor 33R 1/4W ±5% PCS 4 R922 R923 R924 R925
3.30.01.CKX3502P05R MIC Socket CKX-3.5-02 5P PCS 1 PHONE901
3.30.01.CK63521PS3R MIC Socket CK-6.35-21（PJ-617AG-02-EP） 3P PCS 1 MIC900
3.11.03.001UH.00R Bead Inductor 1UH 3.5*6 PCS 3 L900 L901 L902
3.50.03.03P.H0R Connector 3P*2.54 PCS 1 CN901B
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.001CR PCB NC10 PCB-01C 125.5×172.5mm PCS 1 94VO
3.25.05.0000R00JR SMT Resistor 0R 0805 ±5％ PCS 7 JR1007 JR1009 JR1003 JR1004 JR1021 JR1020 JR1005
3.25.05.0022R00JR SMT Resistor 22R 0805 ±5％ PCS 1 R1024
3.25.05.0100R00FR SMT Resistor 100R 0805 ±1％ PCS 4 R1075 R1078 R1077 R1022
R1106 R1104 R1004 R1009 R1007 R1006 R1008 R1003
R1000 R1105 R1005 R1002 R1001
3.25.05.0560R00JR SMT Resistor 560R 0805 ±5％ PCS 2 R1056 R1057
3.25.05.K001R00JR SMT Resistor 1K 0805 ±5％ PCS 1 R1081
3.25.05.K002R40FR SMT Resistor 2K4 0805 ±1％ PCS 2 R1033 R1032
3.25.05.K002R20JR SMT Resistor 2K2 0805 ±5％ PCS 1 R1020
3.25.05.K003R00FR SMT Resistor 3K 0805 ±1％ PCS 2 R1037 R1036
3.25.05.K003R90FR SMT Resistor 3K9 0805 ±1％ PCS 4 R1093 R1092 R1060 R1061
3.25.05.K005R60FR SMT Resistor 5K6 0805 ±1％ PCS 3 R1097 R1096 R1087
3.25.05.K007R50FR SMT Resistor 7K5 0805 ±1％ PCS 2 R1101 R1100
3.25.05.K011R00FR SMT Resistor 11K 0805 ±1％ PCS 2 R1084 R1083
3.25.05.K020R00FR SMT Resistor 20K 0805 ±1％ PCS 1 R1088
R1068 R1067 R1130 R1131 R1133 R1134 R1136 R1138
R1065 R1140 R1066
3.25.05.K033R00FR SMT Resistor 33K 0805 ±1％ PCS 1 R1090
3.25.05.K022R00FR SMT Resistor 22K 0805 ±1％ PCS 3 R1044 R1045 R1040
3.25.05.K056R00JR SMT Resistor 56K 0805 ±5％ PCS 1 R1082
3.25.05.K330R00JR SMT Resistor 330K 0805 ±5％ PCS 1 R1026
3.25.05.M001R00JR SMT Resistor 1M 0805 ±5％ PCS 1 R1132
Position
PCS
9PCS
SMT Capacitor
PCS
PCS
221/50V 0805 ±10％
22uF/16V Φ4×7 +80%-20% 105℃
7.5mm Φ0.6
Electrolytic Capacitor
Electrolytic Capacitor 47uF/16V Φ4×7 +80%-20% 85℃
9Wiring
Position
10K 0805 ±5％
SMT Resistor 470R 0805 ±5％
100R 1/8W ±5%Carbon Film Resistor
3.25.05.K010R00JR
3.26.05.02.221KFR
3.23.03.47UC.W0407R
3.23.03.22UC.X0407R
3.52.06.075R
3.25.05.0470R00JR
14
16
PCS
3.12.A8.0100R00JR
16
PCS
SMT Resistor PCS 11
13
拟制： 校对： 审核： 日期：12/16/2009 第6页，共8页
