NC10 BOM
JR1063 JR1043 JR1042 JR1041 JR1038 JR1037 JR1036 JR1035
JR1073 JR1072 JR1071 JR1070 JR1069 JR1068 JR1025 JR1026
JR1022 JR1006 JR1024 JR1027 JR1066 JR1065 JR1067 JR1023
JR1074 JR1064 JR1031 JR1028 JR1034 JR1033 JR1030 JR1032
JR1029
3.25.06.0120R00JR SMT Resistor 120R 1206 ±5％ PCS 2 R1029 R1028
3.25.06.K022R00JR SMT Resistor 22K 1206 ±5％ PCS 1 R1041
3.26.05.01.20P0JFR SMT Capacitor 20P/50V 0805 ±5％ PCS 2 C1066 C1067
3.26.05.02.101JFR SMT Capacitor 101/50V 0805 ±5％ PCS 3 C1080 C1081 C1083
3.26.05.03.102JFR SMT Capacitor 102/50V 0805 ±5％ PCS 1 C1086
3.26.05.04.103KFR SMT Capacitor 103/50V 0805 ±10％ PCS 1 C1068
C1014 C1001 C1000 C1069 C1070 C1071 C1036 C1037
C1038
3.26.05.06.105MDR SMT Capacitor 105/25V 0805 ±20％ PCS 1 C1091
C1043 C1020 C1018 C1017 C1004 C1007 C1010 C1009
C1090
J1015 J1006 J1003 J1026 J1027 J1028 J1031
J1035
3.52.06.075R Wiring 7.5mm Φ0.6 PCS 6 J1039 J1038 J1037 J1023 J1024 J1025
3.52.06.008R Wiring 8mm Φ0.6 PCS 2 J1000 J1033
3.52.06.010R Wiring 10mm Φ0.6 PCS 5 J1014 J1008 J1032 J1002 J1021
3.52.06.012R Wiring 12mm Φ0.6 PCS 2 J1005 J1029
3.52.06.015R Wiring 15mm Φ0.6 PCS 3 J1036 J1004 J1030
3.07.3B4SD.92R LED 3B4SD-92（020） BLUE PCS 2 LED1017 LED1016
3.07.3R2SDC.24R LED 3R2SDC-24（020） red PCS 8 LED1022 LED1020 LED100
LED1013 LED1012 LED1000 LED1021 LED1010
3.07.3Y4HD.39R LED 3Y4HD-039 yellow PCS 3 LED1006 LED1004 LED1002
3.08.01.4148W05R SMT Diode IN4148 LL-34 PCS 1 D1000
3.05.S9014R SMT Transistor S9014 SOT23 PCS 2 Q1001 Q1000
3.03.78M05.00R SMT IC LM78M05 TO-252-2L ±2％ PCS 1 U1004
3.03.LM1117.33R SMT IC LM1117(3.3v)±2％ SOT223 PCS 1 U1009
3.03.74HC4094.00R SMT IC 74HC4094 SO-16 PHI PCS 1 U1002
3.03.AM2009.00R SMT IC AM2009 LQFP48_N PCS 1 U1007
3.03.HT1621B.00R SMT IC HT1621B SSOP48 PCS 1 IC1000
3.09.T.8MHZR Crystal Oscillator 8MHz HC-49S/SMD PCS 1 X100
3.10.03.RPI352R Coupling RPI-352 PCS 2 O1000 O1001
S1004 S1006 S1022 S1024 S1028 S1026 S1014 S1012
S1030 S1016 S1018 S1020 S1010 S1008
3.28.CU1337A01R Backlight CU1337A-01 White PCS 1 D1002
3.27.88083001R Display TS-880830-01-H2NNP PCS 1 LCD1000
3.32.02.6005N.044R Slide Potentiometer SC6005NOB0X-HAI-044 B10K PCS 1 W1001
3.33.R1102.012R Encoder RS1102SWN0B-HA1-012 PCS 1 RP1000
3.59.A.08P150.H26R Wiring 8P*150MM 2.0 26＃ PCS 1 DIN1004A
3.50.02.12P.W0R Connector 12P*2.0 PCS 1 DIN1002B
3.50.02.04P.W0R Connector 4P*2.0 PCS 1 FC19B
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.002CR PCB NC10 PCB-02C 125.5×172.5mm PCS 1 94VO
3.25.05.0000R00JR SMT Resistor 0R 0805 ±5％ PCS 4 JR1008 JR1040 JR1039 JR1055
3.25.05.0022R00JR SMT Resistor 22R 0805 ±5％ PCS 1 R1025
3.25.05.0100R00FR SMT Resistor 100R 0805 ±1％ PCS 4 R1076 R1079 R1080 R1023
R1109 R1107 R1014 R1019 R1018 R1017 R1016 R1013
R1010 R1108 R1015 R1012 R1011
3.25.05.0560R00JR SMT Resistor 560R 0805 ±5％ PCS 2 R1058 R1059
3.25.05.K002R40FR SMT Resistor 2K4 0805 ±1％ PCS 2 R1034 R1035
3.25.05.K002R20JR SMT Resistor 2K2 0805 ±5％ PCS 1 R1021
3.25.05.K003R00FR SMT Resistor 3K 0805 ±1％ PCS 2 R1038 R1039
3.25.05.K003R90FR SMT Resistor 3K9 0805 ±1％ PCS 4 R1094 R1095 R1062 R1063
3.25.05.K005R60FR SMT Resistor 5K6 0805 ±1％ PCS 2 R1098 R1099
3.25.05.K007R50FR SMT Resistor 7K5 0805 ±1％ PCS 2 R1103 R1102
3.25.05.K011R00FR SMT Resistor 11K 0805 ±1％ PCS 2 R1086 R1085
3.25.05.K020R00FR SMT Resistor 20K 0805 ±1％ PCS 1 R1089
3.25.05.K010R00JR SMT Resistor 10K 0805 ±5％ PCS 2 R1064 R1069
3.25.05.K033R00FR SMT Resistor 33K 0805 ±1％ PCS 1 R1091
3.25.05.K022R00FR SMT Resistor 22K 0805 ±1％ PCS 4 R1046 R1047 R1043 R1042
3.25.05.K330R00JR SMT Resistor 330K 0805 ±5％ PCS 1 R1027
JR1045 JR1044 JR1048 JR1047 JR1046 JR1049 JR1050 JR1051
JR1053 JR1054 JR1056 JR1057 JR1058 JR1059 JR1060 JR1052
JR1061 JR1062
3.25.06.0120R00JR SMT Resistor 120R 1206 ±5％ PCS 2 R1031 R1030
3.26.05.05.104MFR SMT Capacitor 104/50V 0805 ±20％ PCS 3 C1016 C1002 C1003
3.26.12.07.106MDR SMT Capacitor 10UF/25V 1812 ±20％ PCS 7 C1022 C1023 C1021 C1019 C1005 C1012 C1011
3.52.06.005R Wiring 5mm Φ0.6 PCS 2 J1019 J1018
3.52.06.075R Wiring 7.5mm Φ0.6 PCS 3 J1012 J1007 J1013
3.52.06.010R Wiring 10mm Φ0.6 PCS 5 J1009 J1010 J1017 J1020 J1011
3.07.3B4SD.92R LED 3B4SD-92（020） BLUE PCS 2 LED1019 LED1018
3.07.3R2SDC.24R LED 3R2SDC-24（020） red PCS 8 LED1025 LED1023 LED100
LED1015 LED1014 LED1001 LED1024 LED1011
Position
18PCS0R 1206 ±5％
5mm Φ0.6
470R 0805 ±5％ PCS
SMT Capacitor
Wiring
104/50V 0805 ±20％
10U/25V 1812 ±20％SMT Capacitor
SMT Resistor
On-Off
13
SKQSABA010
33PCS0R 1206 ±5％SMT Resistor
PCS
SMT Resistor
3.26.12.07.106MDR
3.25.05.0470R00JR
3.25.06.0000R00JR
3.25.06.0000R00JR
3.52.06.005R
3.26.05.05.104MFR
14
8PCS
PCS 9
9PCS
