Numark iCDMIX 2 Service Manual

NC10 BOM
3.07.3Y4HD.39R LED 3Y4HD-039 yellow PCS 3 LED1007 LED1005 LED1003
3.08.01.4148W05R SMT Diode IN4148 LL-34 PCS 1 D1001
3.05.S9014R SMT Transistor S9014 SOT23 PCS 2 Q1002 Q1003
3.03.78M05.00R SMT IC LM78M5 ±2％ TO252 PCS 1 U1005
3.03.74HC4094.00R SMT IC 74HC4094 SO-16 PHI PCS 1 U1003
3.03.HT1621B.00R SMT IC HT1621B SSOP48 PCS 1 IC1001
3.10.03.RPI352R Coupling RPI-352 PCS 2 O1002 O1003
S1005 S1007 S1023 S1025 S1029 S1027 S1031 S1013
S1015 S1017 S1019 S1021 S1009 S1011
3.28.CU1337A01R Backlight CU1337A-01 White PCS 1 D1003
3.27.88083001R Display TS-880830-01-H2NNP PCS 1 LCD1001
3.32.02.6005N.044R Slide Potentiometer SC6005NOB0X-HAI-044 B10K PCS 1 W1000
3.33.R1102.012R Encoder RS1102SWN0B-HA1-012 PCS 1 RP1001
3.59.A.12P150.H26R Wiring 12P*200MM 2.0 26＃ PCS 1 DIN1002A
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.011AR iPod PCB NC10 PCB-11A 70×37mm PCS 1
3.25.05.0100R00JR SMT Resistor 100R 0805 ±5％ PCS 5 R1422 R1423 R1424 R1425 R1434
3.25.05.K001R00JR SMT Resistor 1K 0805 ±5％ PCS 3 R1435 R1436 R1437
3.25.05.K002R00JR SMT Resistor 2K 0805 ±5％ PCS 2 R1443 R1442
R1409 R1410 R1411 R1412 R1420 R1421 R1438 R1439
R1441 R1440
3.25.05.K006R65JR SMT Resistor 6.65K 0805 ±5％ PCS 4 R1426 R1427 R1428 R1429
3.25.05.K026R70JR SMT Resistor 26.7K 0805 ±5％ PCS 4 R1430 R1431 R1432 R1433
3.25.05.K549R00JR SMT Resistor 549K 0805 ±5％ PCS 1 R1400
3.25.06.0010R00JR SMT Resistor 10R 1206 ±5％ PCS 1 R1444
3.26.05.05.104MFR SMT Capacitor 104/50V 0805 ±20％ PCS 3 C1400 C1401 C1406
3.26.05.05.474MDR SMT Capacitor 474/25V 0805 ±20％ PCS 1 C1411
3.26.05.06.105MDR SMT Capacitor 105/25V 0805 ±20％ PCS 1 C1410
3.26.12.07.106MDR SMT Capacitor 10U/25V 1812 ±20％ PCS 2 C1426 C1425
3.08.01.4148W05R SMT Diode IN4148 LL-34 PCS 2 D1400 D1401
3.05.2SC3326R SMT Transistor 2SC3326 SOT23 PCS 2 Q1405 Q1406
3.05.MBT4401R SMT Transistor MBT4401 SOT23 PCS 1 Q1402
3.05.MBT4403R SMT Transistor MBT4403 SOT23 PCS 2 Q1403 Q1404
3.03.LM1117.50R SMT IC LM117-5V ±2％ SOT223 PCS 1 U1403
3.03.PIC18F1.00R SMT IC PIC18F1XK50 SSOP20 PCS 1 U1402
3.03.TL072.00R SMT IC TL072 DMP8 PCS 1 U1401
iPod Connector iPod connector PCS 1 J1400
3.50.02.05P.H0R Connector 5P*2.0 PCS 1 FC201B
3.50.01.09P.H0R Connector 9P*1.0 PCS 1 J1403A
3.59.B.02P150.H22R Wiring 2P*150MM 2.54 22＃ PCS 1 J1037A
3.55.T.09P050.100R Wiring 9P*50mm PH1.0 PCS 1 J1403A
ERP Code Part name Specification Unit
Q'ty
Remark
3.01.NC10.012AR iPod PCB NC10 PCB-12A 70×42mm PCS 1 94VO
3.25.05.0000R00JR SMT Resistor 0R 0805 ±5％ PCS 1 JR1401
3.25.05.K010R00JR SMT Resistor 10K 0805 ±5％ PCS 7 R1419 R1418 R1417 R1416 R1415 R1414 R1413
3.26.05.05.104MFR SMT Capacitor 104/50V 0805 ±20％ PCS 7 C1409 C1408 C1407 C1405 C1404 C1403 C1402
3.33.EC110.003R Encoder EC110101N2B-HAI-003 PCS 1 E1400
On-Off
SKQSABA010
PCS 4 S1403 S1402 S1401 S1400
ERP Code Part name Specification Unit
Q'ty
Remark
3.54.20.200.YG2R Grounding
200MM 20＃
PCS 1
3.53.20.100.U00R Wiring 100MM 20＃ PCS 1
3.58.E.01P150.U20R Wiring 1P*150MM 20＃ Blue PCS 1
3.58.E.01P100.200R Wiring 1P*100MM 20＃ Red PCS 1
3.59.E.01P100.R20R Wiring 1P*100MM 20＃ Red PCS 1
5.09.01.AV12.00R
Wiring 1.2m PCS 1
Power Cable 1.8M PCS 1
3.31.03.KCD1BR
Power Switch
KCD1
PCS 1
3.30.06.AS03R Socket AS-03 PCS 1
3.31.05.2122A2R Switch L21-22A2 PCS 1
3.35.03.250B.F01AL0R Fuse Tube F1AL 250V~ Φ5×20 PCS 2
5.08.NC10.01R Transformer GLP-090211 NC10 PCS 1
3.43.DA11VZFE .02R Loader DA11VZFE PCS 2
3.44.01.3Y.02R Loader Frame WSL-11VFR PCS 2
Position
Position
Position
3.25.05.K010R00JR
On-Off
SKQSABA010
10K 0805 ±5％
FR-4 dual-layer
PCS
10PCSSMT Resistor
14
拟制： 校对： 审核： 日期：12/16/2009 第8页，共8页
