18
Appendix (English)
Technical Specifications
Output Power
40 W (20 W x 2)
Low-Frequency Driver
5” (127 mm) woofer
High-Frequencer Driver
1” (25 mm) silk-dome tweeter
Inputs / Outputs
(2) 1/4” (6.35 mm) TRS audio inputs (left and right)
(1) RCA stereo input (left and right)
(1) 1/4” (6.35 mm) TRS audio connection between speakers
(1) 4-pin LED connection between speakers
Input Impedance
10
Ω
Frequency Response
55 Hz – 20 KHz
Light
(14) 0.2 W multi-color LEDs per speaker
Power
100-240V, 50/60Hz; universal switching power supply
Dimensions
(width x depth x height;
each speaker)
7.25” x 9.0” x 10.63”
184 mm x 229 mm x 270 mm
Weight Right Speaker: 7.5 lbs. / 3.4 kg
Left Speaker: 6.75 lbs. / 3.1 kg
Specifications are subject to change without notice.
Trademarks and Licenses
Numark is a trademark of inMusic Brands, Inc., registered in the U.S. and other countries.
All other product or company names are trademarks or registered trademarks of their
respective owners.
