Numark NS6 Service Manual

...3 ICBA033FP IC BA033FP 1 U26
...3 ICSN74HC14D IC SN74HC14D 1 U8
...3 ICYH99C03 IC YH99C03 (STM32F102R8T6+Program) 1 U7
....4 ICSTM32F102R8T6 IC STM32F102R8T6 TQFP64 1 -
...3 LDKPT-2012QWF-D LED White SMD 0805 47
LED1~9,11,13,34,38,39,42,45,55,59,78~93,122,124,12
6,128,164,166,168,170,176,203,205,208,210
...3 LDKPTC2012SURCK RED LED KPTC2012 SURCK 0805 106
LED10,12,14~33,35~37,40,41,43,44,46~54,56~58,60~
75,121,123,125,127,129,131,132~137,139~143,145~1
50,163,165,167,169,171~174,177~180,202,204,211~2
19,238,243,244
...3 LDYH-11R9W2 LED BAR 2 LEDB2,3
...3 RS000004J06 RESISTOR 0Ω 5% SMD 1206 1 R0
...3 RS000010J03 RESISTOR 0Ω 5% SMD 0603 1 R440
...3 RS000110F03 RESISTOR 1Ω 1% SMD 0603 1 R2
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 4 R41,246~248
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 8 R15,52,234~236,243~245
...3 RS004710F03 RESISTOR 47Ω 1% SMD 0603 63
R1,11,13,18,21~24,27,30,34~36,38~40,42,43~45,51,5
3~66,72,73,75~77,81,89,93~95,108~118,124,125,129~
131,161,162
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 10 R3,4,20,37,67,68,71,141~143
...3 RS013010F03 RESISTOR 130Ω 1% SMD 0603 44
R140,144,145,147,148,152~158,169,172~184,188,250,
366~381
...3 RS01K310F03 RESISTOR 1.3K 1% SMD 0603 1 R97
...3 RS022010F03 RESISTOR 220Ω 1% SMD 0603 39
R190,191,193,194,204~213,233,238,239,241,249,305,
307,309,311,328,351,353,355,357,403~413
...3 RS033010F03 RESISTOR 330Ω 1% SMD 0603 52
R120,146,149~151,167,185~187,189,192,195,196~20
3,214~218,220~222,225~232,240,304,306,308,310,35
0,352,354,356,361,362,364,387,390,392,436
...3 RS033K10F03 RESISTOR 33K 1% SMD 0603 2 R6,9
...3 RS047010F03 RESISTOR 470Ω 1% SMD 0603 7 R251,256~258,393~395
...3 RS047510F03 RESISTOR 475Ω 1% SMD 0603 2 R5,8
...3 RS04K310F03 RESISTOR 4.3K 1% SMD 0603 22 R400~402,414~426,428~433
...3 RS068K10F03 RESISTOR 68K 1% SMD 0603 1 R33
...3 RS075010F03 RESISTOR 750Ω 1% SMD 0603 10 R160,163,165,168,170,171,252~255
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 3 R31,32,237
...3 RS3K0110F03 RESISTOR 3K01 1/10W SMD 1/10W 0603 1 R133
...3 RS6K8110F03 RESISTOR 6.81K 1% SMD 0603 1 R82
...3 SWDC11B2021431 Switch Rotational Encode 20Pulse Push 18.8mm 2 E2,3
...3 SWEVQ11L05R Switch Tact 5mm 160g Horizontal DIP 54 S1~8,13~15,18~21,31~38,40~69,72
...3 SWSSFUB22-10K Switch Slide Single Row 180° 4 S9~12
...3 TE10200601 6P CONNECTOR 1 (J9)
...3 TE622500403 4P CONNECTOR 1 (J10)
...3 TE962542001 TERMINAL 20P 2.54MM 1 (J2)
...3 TR2SK1828 MOSFET N-CH 20V MAIN 2-Pin 2 Q5,6
...3 VRR10301701 VARIABLE 10KB 6 P1,2,5,26,27,41
...3 VRR10301704 Poltertiomaeter Rotary Volume 10K2B 12 P6,9,14,16,17,20,28,30,31,33~35
...3 VRS10303006 Potentiometer Slide 10k 15mm 1 P24
...3 VRS10310013 Potentiometer Rotary Valume 10KB 1 P23
...3 VRS50304524 Potentiomeper Slide 50K2B 4 P15,21,32,36
...3 XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamental 1 X1
..2 TWPC10C006B01 SenSer PCB ASS'Y 1 71
...3 CS104K5003X7R CERAMIC 0.1uF/50V 10% 0603 X7R 1 C251
...3 DIHEDS-9700F50 Optical Encoder 1 PH1
...3 TE622000401 4P CONNECTOR 1 (CON10)
..2 TWPC10C006C01 SenSer PCB ASS'Y 1 72
...3 CS104K5003X7R CERAMIC 0.1uF/50V 10% 0603 X7R 1 C252
...3 DIHEDS-9700F50 Optical Encoder 1 PH2
...3 TE622000401 4P CONNECTOR 1 (CON11)
..2 TWPC10C006D01 Shielding PCB ASS'Y 1 57
0.1 TWPC10C00701 LEFT CONTROL PCB ASS'Y 1

Numark NS6 Specifications

General

Sample rate	441 kHz
Channels quantity	4 channels
Digital sound processing	24 bit
MIDI out	Yes
Booth out (1/4\")	1
Dimensions (WxDxH)	603 x 340 x 64 mm

Weight and Dimensions

Weight	6330 g
