Numatic CVC 370 Owner's Instructions

Motor AirFlo Suction Cleaning
Range
Class
CVC 370
WV 370
WV 470
1200W
1200W
1200W
40 L/sec
40 L/sec
40 L/sec
2500 mm
2500 mm
2500 mm
28.8m
28.8m
28.8m
II
Capacity
Dry
Capacity
Wet
Size Weight Sound
Pressure
CVC 370
WV 370
WV 470
15 Ltrs
15 Ltrs
27 Ltrs
9 Ltrs
9 Ltrs
20 Ltrs
355x355x510
355x355x510
355x355x710
7.1 Kgs
7.1 Kgs
9.6 Kgs
73-77 dB
(IEC 60704-2-1)
Uncertianty: 0.2 dB (A)
Fault Finding
This machine can be used for wet and dry pick up.
Dry Mode
If the vacuum cleaner stops working switch off and remove the plug from the wall before
investigating were the fault lies.
If the vacuum cleaner will not pick up any debris from the surface, switch off and remove the plug from the wall,
inspect the oor tool, wands and hose for blockages, if no blockages are found, the dust bag may be full if the
dust bag is not full the lter may be blocked.
Wet Mode
If the vacuum cleaner stops working switch off and remove the plug from the wall before investigating were the
fault lies.
If the vacuum cleaner has a blockage and will not pick up liquid, switch off and remove the plug from the wall,
has the oat valve operated, this will shut off the suction and the pitch of the vacuum motor will change Remove
the power head and empty the liquid out of the container, if the container is empty, check that the oor tool
wands and hose are not blocked.
After use always inspect the machine for damage.
Data

Numatic CVC 370 Specifications

General

Brand	Numatic
Model	CVC 370
Category	Vacuum Cleaner
Language	English
