Nuna leaf grow - Recline and Base Adjustment; Recline Position Guidelines; Adjusting Recline; Detaching Seat from Base

EN
1
2
click
Recline
There are three recline positions.
1 - For stage one use, only use in the LOWEST, MOST
RECLINED position.
You MUST use the harness for stage one use.
The harness is not required for stage two use.
2 - ANY recline position can be used for stage two use.
3 - To lower or raise the recline, pull up on the top of the seat
to release the connection (1). Then press in on the recline
adjustment button (2) and adjust the seat to the desired
recline position. A “click” sound means the recline
position is engaged.
Base
4 - To remove the seat from the base, insert a flat head
screwdriver into the slot on the back of the seat mount,
and press to disengage the connection.
5 - Once the connection is disengaged, slide the seat off
the base mount.
DO NOT detach the seat from the base by any other
method.
1 4
5
3
2
18 19LEAF grow instructions LEAF grow instructions
EN
