MODEL 665RP
Page 6
SERVICE PARTS
KEY NO. PART NO. DESCRIPTION
1 97017451 Housing
2 101183000 Damper / Duct Connector
3 44388000 Mounting Bracket (4 Req.)
4 99270981 Receptacle, White
99270982 Receptacle, Black
99270489 Receptacle, Red
5 82403000 Fan Blower Wheel
6 99080592 Fan Motor
7 97017080 Fan Motor Plate Assembly
8 99260428 Nut (4 Req.)
9 89852000 Grille Assembly (includes Key No. 13)
10 98010306 Light Reflector
11 97005316 Acorn Nut
12 99770112 Light Socket
13 53740000 Light Lens
14 97005058 Bolt Assembly
15 99020134 Heater Blower Wheel
16 99150576 #8 x 3/8 Sheet Metal Screw (5 Req.)
17 93260457 #10 - 32 Nut (7 Req.)
(2 included in Key No. 16)
18 99270107 Heater Hooks (5 Req.)
19 98010295 Heater Scroll Cover
20 97017070 Heater Scroll Housing
21 99080593 Heater Motor
22 98004514 Heater Element
23 99260512 Tinnerman Nut
24 99420666 Wire Clip (2 Req.)
25 98010286 Exhaust Fan Scroll Band
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
16
19
20
21
22
WARRANTY
99045036A
23
24
25
One Year Limited Warranty
WARRANTY OWNER: Broan-NuTone warrants to the original consumer purchaser of its products that such products will be free from defects
in materials or workmanship for a period of one (1) year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
During this one year period, Broan-NuTone will, at its option, repair or replace, without charge, any product or part which is found to be defective
under normal use and service. THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS OR TUBES, FILTERS, DUCT, ROOF
CAPS, WALL CAPS AND OTHER ACCESSORIES FOR DUCTING. This warranty does not cover (a) normal maintenance and service or (b) any
products or parts which have been subject to misuse, negligence, accident, improper maintenance or repair (other than by Broan-NuTone), faulty
installation or installation contrary to recommended installation instructions.
The duration of any implied warranty is limited to the one year period as specified for the express warranty. Some states do not allow limitation
on how long an implied warranty lasts, so the above limitation may not apply to you.
BROAN-NUTONE’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN-NUTONE’S OPTION, SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE
REMEDY UNDER THIS WARRANTY. BROAN-NUTONE SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARIS-
ING OUT OF OR IN CONNECTION WITH PRODUCT USE OR PERFORMANCE. Some states do not allow the exclusion or limitation of incidental
or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state. This warranty supersedes all prior warranties.
WARRANTY SERVICE: To qualify for warranty service, you must (a) notify Broan-NuTone at the address or telephone number below, (b) give the
model number and part identification and (c) describe the nature of any defect in the product or part. At the time of requesting warranty service,
you must present evidence of the original purchase date.
Date of Installation
Builder or Installer
Model No. and Product Description
IF YOU NEED ASSISTANCE OR SERVICE - CONTACT:
Broan-NuTone LLC Hartford, Wisconsin www.nutone.com 888-336-3948
Rev. 08/2007
