4
1
10
Install grille.
Connect 3 plugs from
housing as shown. Squeeze
grille springs and insert into
slots in blower. Push grille up
against ceiling.
If grille spring
becomes dislodged
from grille - snap it
back into place as
shown.
1101688A
1
11
Install wall control.
1
2
Note: Location of wall control must be within
20-feet (not obstructed) of Chroma grille.
Use one of two methods to attach control:
(1) Mount control to new single-gang
electrical box. (Recommended method)
(2) Mount control to wall with clearance
hole in wall.
Remove control module, install 2-AAA
batteries, and replace module.
Snap control cover in place. Note: Metallic
cover plates are not recommended.
1
12
Pair wall control.
Turn on power to fan. Within 3 minutes, hold
white light button for 5+ seconds. White light
button will flash to confirm pairing.
Note orientation of tab
and buttons.
WHITE
LIGHT
BUTTON
To Next Page
