SPECIFIC SAFETY INSTRUCTIONS
This machine must be firmly secured to a suitable workbench or
other stable work surface.
When selecting a suitable location for mounting this machine
consideration must be given to the maximum length of the
material to be drilled or machined and the position of the
Before starting the machine ensure that drills and other
recommended cutting tools are fitted correctly, that all the
securing bolts are tight and all guards are fitted and are operating
correctly and that the chuck key and any other adjustment tools
Keep hands well away from rotating drills and other cutting tools
When drilling use the correct cutting lubricant/coolant for the
material being drilled. Use only sufficient to prevent the drill
from overheating and make sure that it is kept well away from
electrical components. Never use water as a coolant.
Keep drills, and other cutters sharp and in good condition.
This will improve cutting and reduce the load on the Machine
ensuring a longer life of the cutting tools and the machine.
Use only drill bits, cutters and other accessories recommended
Select the correct spindle speed for the size of drill being used.
See the instruction manual.
Do not attempt to modify the machine or its accessories in
Do not force the machine let the machine do the work this will
reduce the wear on the machine and cutter and increase its
efficiency and operating life.
Use approved safety glasses or goggles, face mask and Ear
defenders when using for prolonged periods.
When drilling long lengths ensure that there is adequate support
at both ends of the material.
Never use the machine without the safety guards in position and
Ensure that the work piece is free from any nails or other foreign
objects that could damage the drills and other cutting tools.
Always secure the workpiece in a suitable drill vice. Never try
and secure the workpiece with your hands.
Be aware that swarf can be very sharp and hot and
can fly off the rotating drill. When handling swarf always wear
suitable gloves. Swarf should not be disposed of with domestic
waste, it should be disposed of at a recycling centre.
Never leave the machine running while unattended.
Always allow the machine to come to a complete stop and
disconnect from the power supply before leaving the unit
This manual covers the assembly and operation of
both workbench and floor mounted drilling machines. These
instructions can be used for both types of machine, the only
variation being the location and mounting of the drilling machine
either on a workbench or onto the floor.
COMPONENTS AND CONTROLS (PIC. 1)
The items marked with an * should be checked off when
This packaging contains sharp objects. Take care
when unpacking. This machine could require two persons to
lift, assemble and move this machine. Remove the machine,
together with the accessories supplied, from the packaging.
Check carefully to ensure that the machine is in good condition
and account for all the accessories listed in this manual. Also
make sure that all the accessories are complete. If any parts
are found to be missing, the machine and its accessories should
be returned together in their original packaging to the retailer.
Do not throw the packaging away, keep it safe throughout the
guarantee period, then recycle if possible, otherwise dispose
of it by the proper means. Do not let children play with empty
plastic bags due to the risk of suffocation.
When determining where to locate or permanently fix the
machine, consideration must be given to the following points.
Is there a suitable mains outlet socket near by. If the machine
is to be permanently mounted onto a bench is the bench at a
suitable height and is it strong and stable enough to carry the
Rack upper retaining Collar
Rack to allow table to be raised or lowered
Start/Stop with emergency stop
Chuck, drift and 2 hexagonal keys
