NUUO SCB-A08 - LED Definition

- 7 -
2.1. LED Definition
Name
Description
Link
Green – 100 BaseTX Ethernet connection established
Yellow – 10 BaseT Ethernet connection established
Run
Flashing Green – system is ready
Serial 1
Green – connection established
Flashing Green – data is transmitting
DI/DO
Green – connection established
Flashing Green – data is transmitting
DI1~DI8
Green – Status ON
DO1~DO8
Green – Status ON
