Nuvo Essentia NV-E6GMS-DC - Back Panel Features

4
EssentiaBackPanel
1. TheEssentiawillacceptuptosixaudiosources.TheseareconnectedtoEssentia'smainandexpanderamplifiers
withstandardstereoRCAcables.
2. Thesepreamplineoutsareusedforsendinganaudiosignaltoanexternalpoweramplifier.Thisisusefulfor
largeareasthatrequireadditionalpairsofspeakers.Theseoutputsareconstant,soanamplifierconnectedtoitwillnot
changevolumewiththatzone'sControlPad.Zones1and2bothhaveafixedlineout.
3. Thesepreamplineoutsarealsousedforsendinganaudiosignaltoanexternalpoweramplifier.Usethe
variableoutputwhenyouwantthevolumeoftheadditionalamplifiertobecontrolledbythezone'sControlPad.LiketheFixed
Lineouts,zones1and2eachhaveavariablelineout.
4. These5-voltoutputsarezonespecificvoltagetriggersforexternalamplification.
5. This25-pinconnectionconsolidatesthezonespeakerconnectionstothebackoftheAllporthubintoa
singlecableconnectiononthebackoftheEssentiaamplifier.
6 IRsignalsreceivedfromtheControlPadsarepassedthroughtheIRoutputstothesourceequipmentusing
thesuppliedIRemitters.Outputs1-6areroutedtothecorrespondingsources,andtheSUMoutputiscommonandwillpassall
IRsignals.
7. The9-pinRS232connectionisabi-directionalserialportthatallowstheEssentiaSystemtobecontrolledbyan
externalhomeautomationdevice.Itisalsousedforconfigurationprogrammingdownload.
8. Thisisaconstant5-voltoutputfortriggeringexternalequipment.Thereisnovoltageoutputwhenthezonesareoff.
9. ThisRJ45connectionistheinputforallzoneinformationcomingfromtheSystem’sControlPadsandall
communicationwiththeNuVoNetSuitesourcecomponents.Thisconnectionismadeusingthesuppliedpre-terminatedCAT5or
anynetworkCAT5cable.
10. ThisRJ45outputisdesignedtoconnecttotheLinkinputontheEssentiaExpandercomponentandtransfersallzone
controlcommandsfromtheMainUnit'sNuVoNetorRS232commandinputtotheExpanderforanadditionalsixzones.
11. Thisinputisdesignedtotemporarilymuteanyaudioplayingthroughthesystemwhenthedoorbellorphonerings.This
worksinconjunctionwiththeNuVoNV-MI1muteinterfaceaccessory.Italsoactsasatriggerforwholehousepagingthrough
anythirdpartypagingdevicewhensetforthisfunctionintheConfiguratorSoftware.
12. AdetachablepowercordconnectsthesystemtoanexternalACpowersupply.
SourceInputs:
FixedLineouts:
VariableLineouts:
ZoneTriggerOutputs:
AllportConnection:
.IRemitterOutputs:
RS232:
Status:
NuVoNet:
Link:
Mute:
AC:
5 6
FIXED VAR
ZONE
1
TRIG
ZONE
2
STATUS
NuVoN et
RS232
1
SUM
ALLPORTCONNECTION
IROUTPUTS
2 3 4 5 6
LINK
MUTE
MADEINC HI NA
100~240V50~6 0H z13 0W
1807
N18 39
www .nu vot echno logie s.com
MODEL NV-E6 GM
SIXS OURCES IXZONE
AUD IODIST RIBUT IONSYS TEM
303 3118
NuVoTe chn olo giesLL C H ebr on,K entuc kyUSA•
CON FORMST OUL
STD .6006 5CERTI FIED
TOCA N/CSA ST D.
C22 .2No.6 0065: 03
RoHS
1
2
3
4
5
6
7
8
9
10
11
12
