Nuvo T2 - Page 6

NV-T2DF Wiring Diagram
Diagram is shown with the NuVo Concerto System and NuVoNet.
NV-T2DF Package Contents:
1 NV-T2DF Dual AM, FM, WX Tuner
1 NV-T2FAA Active AM/FM Antenna
1 NV-T2RC3 Remote Control
2 NV-RCA1 Stereo RCA Audio Cables
1 NV-AC1 2 Meter Coaxial Antenna Cable
1 NV-PC2 North American Power Cable (North American model only)
1 pr. NV-REM1U Single Space Rack Ear Mounts
NV-T2DX Package Contents
1 NV-T2DX Dual XM Tuner
1 NV-T2XAA Active XM Antenna
1 NV-FBC F-Type Barrel Connector
1 NV-RC3 Remote Control
2 NV-RCA1 Stereo RCA Audio Cables
1 NV-PC2 North American Power Cable
1 pr. NV-REM1U Single Space Rack Ear Mounts
