4 | nVent.com
NGC-UIT2-EX Cut Out Dimensions
190.7 mm
(7.508 in)
10.82 mm
(0.426 in)
88.39 mm
(3.480 in)
Ø 4.83 mm (0.190 in) X12
71.48 mm
(2.814 in)
71.48 mm
(2.814 in)
71.48 mm
(2.814 in)
Panel Cut Out Area
Top of Display
Drawing
NOT TO SCALE
Drawing
NOT TO SCALE
11.1 mm
(0.437 in)
88.39 mm
(3.480 in)
88.39 mm
(3.480 in)
243.54 mm
(9.588 in)
Panel Cut Out
Panel Cut Out

nvent Raychem NGC-UIT2-EX Specifications

General

Brand	nvent
Model	Raychem NGC-UIT2-EX
Category	Touch terminals
Language	English
