NVLink Bridge
Quadro GV100 NVLink Bridge
> Install the first Quadro GV100 graphics card into the primary
PCI Express x16 slot on the motherboard.
> Install the second Quadro GV100 graphics card into the
adjacent PCI Express x16 slot.
> Connect the two Quadro GV100 NVLink Bridge connectors
into the labeled NVLink ports on the two Quadro GV100
graphics cards.
Note: The only supported Quadro GV100 NVLink Bridge
configuration is with two connectors.
EN
Quadro GV100 NVLink Bridge Quick Start Guide | Page 1
HARDWARE INSTALLATION
