Page 4 | Quadro GV100 Quick Start Guide
EN
6 Install the card into the primary x16 PCI slot. Press gently on
the card until it is seated securely in the slot.
Install the graphics card into
the primary x16 PCI slot.
The Quadro GV100 is a dual-slot
GPU and will cover the adjacent
slot.
7 Secure the card to the system frame using the screw(s)
removed in step 5.
8 Connect the supplied auxiliary power cable(s) from the
power supply to the back edge of the GPU.
Use the 8-pin to dual 6-pin
auxiliary cable, if the power
supply does not have an 8-pin
auxiliary cable. Connecting
a single 6-pin auxiliary cable
directly to the GV100 is not
recommended.
Note: Use the recommended power connector guidelines at
www.nvidia.com/quadropowerguidelines.
9 Install the side panel removed in step 4.
