Nvidia RTX A5000 User Manual

1 Remove the current graphics driver installed on the host system.
2 Power down your system.
3 Unplug the power cord from the AC power source.
4 Remove the side panel from your system to gain access to the
motherboard.
Note: Reference your specific computer documents
for instructions on accessing the motherboard in
your computer.
03
HARDWARE
INSTALLATION

Nvidia RTX A5000 Specifications

General

GPU Architecture	Ampere
CUDA Cores	8192
Memory Size	24 GB
Memory Interface	384-bit
Memory Bandwidth	768 GB/s
TDP	230 W
NVLink	Yes
Boost Clock	1695 MHz
Interface	PCIe 4.0 x16
Tensor Cores	256
RT Cores	64
Display Outputs	4x DisplayPort 1.4a
Max Resolution	7680 x 4320 @60Hz
Power Connectors	1 x 8-pin
Form Factor	4.4" H x 10.5" L, Dual Slot
