8
ICs Default Settings
1． TDA9351/9353
MI Items Vari
able
Prese
t
discription
M0 AVL ON/OFF ON Auto volume control select on menu.on:open;off:close.
FSL ON/OFF ON Vertical sync slice level select.off:auto;on: 60% of complex sync
FMWS 0-2 0 FM demodulation band width.0:standard(225khz);1: for over FM
modulation(450KHz);2:for over FM modulation(600KHz)
FFI ON/OFF OFF
IF PLL filter.on:short
time constant;off:normal
OSO ON/OFF ON Decreasing bright spot when switch off stay at the vertical over scan
period .ON:open;OFF:close.
FCO ON/OFF OFF Forced color system. On:only for single color system(for example
VCR); off:normal
WOOFER ON/OFF OFF Woofer select on menu.on:open;off:close.
DVD DELAY 0-8 2 Delay of turning to TV from DVD
DVD/VCD ON/OFF OFF Display on screen.on:DVD;OFF:VCD.
M1 BAND 0~2 2 Tuner band mode select,see attached table 1
AV OPT ON/OFF OFF AV control logic option,see table 2
AV CFG* 0~8 3 AV input stuts select, see table 2
NTSC MX USA/JAP USA NTSC matrix select(USA or JAPAN)
VIDEO OUT IF/CVBS CVBS AV output mode select:TV /display on screen
PRO 0-3 0 Sharp the boardline
PIN5 NTSC Compatible with other hardware, see table3
PIN7 VOL1 Compatible with other hardware, see table3
PIN8 MUTE Compatible with other hardware, see table3
START TIME 6-15 S 8 Delay time after power on
M2 VISION IF 38/38.9/4
5.75/58.7
5
38.9M IF select
DK ON/OFF OFF Sound system select
BG ON/OFF ON Sound system select
I ON/OFF OFF Sound system select
M ON/OFF OFF Sound system select
SIF PREFER DK/I/BG/
M
BG Sound system priority select when Auto scan
AUTO SOUND ON/OFF ON Sound system auto identify when auo scan
POWER OPT 0-2 2 Switch on mode,0:standby,1:power on;2:remember last time.
TXT DEF 0-3 0 Text language selset
TXT BRI 0-63 63 Text brightness set
SPANISH BIT ON/OFF OFF Spanish text bit
MI
M3 ENGLISH ON/OFF ON Language option
ARABIC ON/OFF OFF Language option
