SPLASH SCREENS
IR OUTHDMI IN HDMI OUT
HDMI 1 HDMI 2
CONNECTING SCREEN:
Receiver is searching for
Transmitter. Please wait.
TROUBLESHOOTING SCREEN:
Receiver has not yet found
Transmitter, please check the
displayed tips to ensure connection.
PAIRING MODE SCREEN:
Receiver has entered manual
pairing mode.
LED Behavior
WHEN CONNECTED:
LED will remain solid white permanently
WHEN NOT CONNECTED:
LED will turn on for 1 second, then off for
3 seconds and repeat
DEVICE
RECEIVER
IR OUTHDMI IN HDMI OUT
TRANSMITTER
TRANSMITTER
HDMI 1 HDMI 2
IR OUT
IR OUT IR INPOWER POWER
HDMI IN
HDMI IN
HDMI OUT
HDMI OUT HDMI OUT
TV
IR
HDTV
DEVICE
TOP VIEW
TRANSMITTER
RECEIVER
DEVICE
IR
IR sensor must be in front
of IR window of device.
Pairing Button:
To use to pair with additional receivers or to
manually repair included Transmitter and
Receiver.
NOTE: Tranmitter and Receiver are already
paired when manufactured.
3
WHAT'S INCLUDED
• Digital Wireless HD Transmitter
• Digital Wireless HD Receiver
• 1 External IR Receiver
• 1 External IR Emitter
• 2x 100-240V AC Power Adapters
• 5ft HDMI Cable
• 2x Screws/Screw Anchors
• 1 Year Warranty
• Lifetime Customer Support
TRANSMITTER RECEIVER
