conditions.
· The acce
p
table tolerance to volta
g
e fluctuation is +/- 10% durin
g
o
p
eration.
PacFIRST HEAT PUMP
english
See ANNEX 1 for electrical diagram detail.
33
MODEL
PacFIRST 4.5
MONO
PacFIRST 6.5
MONO
PacFIRST 8.5
MONO
PacFIRST 13.5
MONO
PacFIRST 13.5
TRI
PacFIRST 17
MONO
PacFIRST 17
TRI
PacFIRST 21
MONO
PacFIRST 21
TRI
BLPOM200R BLPOM300R BLPOM400R BLPOM600R BLPOT600R BLPOM700R BLPOT700R BLPOM800R BLPOT800R
VOLTAGE / FREQUENCY
(V/Ph/Hz)
230/1/50 230/1/50 230/1/50 230/1/50 380/3/50 230/1/50 380/3/50 230/1/50 380/3/50
SHORT CIRCUIT
PROTECTION
DEVICE
NOMINAL
CURRENT
3,8 A 6,3 A 8,3 A 12,0 A 4,6 A 16,0 A 6,0 A 21 A 7,8 A
RESIDUAL
CURRENT
LIMIT
25mA 25mA 30mA 45 mA 25mA 60 mA 25 mA 100 mA 35 mA
FUSE GAUGE 16 A 20 A 20 A 32 A 16 A 40 A 20 A 60 A 20 A
SUPPLY GAUGE 3 x 1,5 3 x 1,5 3 x 2,5 3 x 2,5 5 x 1,5 3 x 4 5 x 2,5 3 x 4 5 x 2,5
