ERROR MESSAGE
】
・
The following are error messages and what they mean.
Open Err1
①
The serial port does not open.
②
Check if the COM number of the serial port is correct.
③
Check the connection between the ECU and the PC.
RES TO
①
Response signals from EC-11 are not received
②
Check if the ECU is turned on and electric power is properly supplied.
③
Check the connection between the ECU and the PC.
Now Open
①
The serial port is open.
②
Click [OK] button and continue the operation.
Open Err2
①
It failed to acquire the serial port settings from the PC.
②
Check the connection between the ECU and the PC.
Open Err3
①
It failed the serial port setting in the PC.
②
Check the connection between the ECU and the PC.
Open Err10
①
The serial port is still closed. Open the serial port.
RES SUM ERR
①
There is an error in the received data from the ECU.
②
Check the connection between the ECU and the PC.
OPERATION (EC11-LINK)
