CAN〔High〕 CAN〔電源+5V〕
CAN〔GND〕 CAN〔Low〕
Serial communication〔TX〕 Serial communication〔Power supply DC+5V〕
Serial communication〔GND〕 Serial communication〔RX〕
Throttle signal input〔SIGNAL〕 Power supply DC+5V (Expansion)
Fuel trim signal input〔SIGNAL〕 Throttle signal input〔GND〕
External input〔Digital 0-5V〕 Fuel trim signal input〔GND〕
External output External input〔GND〕
〔Open collector max10V，IOL=max5mA〕 External output〔GND〕
Crankshaft rotation sensor〔+5V〕 Crankshaft rotation sensor〔SIGNAL〕
Crankshaft rotation sensor〔GND〕 Fuel pressure sensor〔+5V〕
Fuel pressure sensor〔SIGNAL〕 Fuel pressure sensor〔GND〕
(GND) Manifold air pressure sensor〔+5V〕
Manifold air pressure sensor〔SIGNAL〕 Manifold air pressure sensor〔GND〕
Intake air temperature sensor〔+〕 Intake air temperature sensor〔-〕
Cylinder head temperature sensor〔+〕 Cylinder head temperature sensor〔-〕
GND(Shield)
14
30
15
31
8 24
9
25
26
21
6 22
7 23
11
27
12
28
13
29
10
Not connected except to enclose with
pin assignment
1 17
2 18
3 19
4 20
5
16
32
CN1
CN2
1
17
16
32
