CN2
Ignition signal outputGND Ignition signal outputIOL=max7mA
InjectorSIGNAL IOL=max1A Injector Power supply DC+12V
Fuel pumpSIGNAL IOL=max1A Fuel pumpPower supply DC+12V
Throttle servoSIGNAL Throttle servoPower supply DC+5V
Power supply DC+5V (Expansion) Throttle servoGND
External outputGND (Expansion) External outputDigital 0-5V (Expansion)
Power supplyDC1017VMAX1.5A Power supplyDC1017VMAX1.5A
Power supplyGND Power supplyGND
.
16
15
1 9
2 10
3 11
7
8
4 12
5 13
6 14
Not connected except to enclose with
pin assignment
26
1
8
916
