O.S. engine MAX-91FX User Manual

9
8
7
6
5
4
3
2
1
1-1
1-2
2-1
N.+M3.5X6
9
8
7
6
5
4
3
2
1
2-1
1-2
1-1
N.+M3.5X6
CARBURETOR 40B
(50SX,40,46FX)
1
1-1
1-2
2
2-1
3
4
5
6
7
8
9
Throttle Lever Assembly
Throttle Lever Fixing Screw
Throttle Lever
Mixture Control Valve
"O"Ring
Carburettor Rotor
Rotor Spring
Carburettor Body
Throttle Stop Screw (W/Spring)
Fuel Inlet (W/Washer)
Carburettor Gasket
Carburettor Fixing Screw
22781401
22781420
22781411
27783600
22781800
25681200
26781506
25681100
25681620
22681953
46215000
25081700
CARBURETOR 60C (61FX)
22781401
22781411
22781420
27783600
22781800
27783200
26781506
27783100
25681620
22681953
46215000
25081700
Throttle Lever Assembly
Throttle Lever
Throttle Lever Fixing Screw
Mixture Control Valve
"O"Ring
Carburettor Rotor
Rotor Spring
Carburettor Body
Throttle Stop Screw (W/Spring)
Fuel Inlet (W/Washer)
Carburetor Gasket
Carburetor Retaining Screw
C
…
Cap Screw F
…
Flat Head Screw
N
…
Round Head Screw S
…
Set Screw
No.
1
1-1
1-2
2
2-1
3
4
5
6
7
8
9
No.
Code No.
Description
Code No.
Description
✽ Type of screw
34
