O2 Concepts, LLC Oxlife FREEDOM User Manual

9
Specifications
DIMENSIONS
Device Dimensions
H: 9.4” (23.87cm) W: 9.0” (22.86 cm) D: 3.4” (8.63cm)
WEIGHTS
Device
4.53 lbs. (2.05kg)
Battery
1.35 lbs. (0.61 kg)
AC Charger
1.2 lbs. (0.54 kg)
DC Charger
1.4 lbs. (0.63 kg)
MODES OF OPERATION
Flow Control Settings
5 Settings: 1 to 5
Breathing Frequency
Up to 40 Breaths per Minute (BPM)
Inspiratory Trigger Sensitivity
≤ 0.2 cm H2O
Battery Specification
14.4V Lithium Ion Battery
External Power Supply Power
Input
AC power: 100 - 240V AC, 50/60 Hz @ 1.0-2.0 amps
DC power: 12-15V DC; Recommended: 15A outlet at 12V
Altitude
0-13,123ft or (0-4000m)
Oxygen Purity
91% ± 4% (87 – 95%) on all settings; measured purity values are within ± 2% of actual
values; there is no variation in purity within the operating altitude. This applies to the full
range of environmental operating conditions.
Operating Temperature
50°F (10°) to 104°FSee (40°C)
Operating Humidity
10% - 95% @ 82.4°F (28°C)
Operating Atmospheric Pressure
101kPa to 63kPa
Operating Environment
Free of smoke, pollutants and fumes363
Transport/ Storage Temperature
-4°F (-20°C) to 140°F (60°C)
Transport/ Storage Humidity
0 – 95% non-condensing
Cannula Specification
DO NOT use cannula tubing longer than 7ft (2.13m)
Sound Level (Sound Pressure)
56dBA (on setting 5)
Alarm Sound Level
All alarms triggered by the device will be 48dBA or higher at 1 meter from the unit.
Maximum Outlet Pressure
Less than 137kPa (normal or single fault)
Warranty
Device: 3 years/Sieve Tubes: 1year/Accessories: 1 year

O2 Concepts, LLC Oxlife FREEDOM Specifications

General

Brand	O2 Concepts, LLC
Model	Oxlife FREEDOM
Category	Oxygen Equipment
Language	English
