29
Pressure loss due to hoses
Use large hoses if possible in order to minimise pressure loss.
Please use the following hose diameters for hoses up to 4 m in
length:
Filtoclear 3000 1 – 1¼ inches
Filtoclear 6000 1 – 1½ inches
Filtoclear 11,000 1¼ - 1½ inches
For hoses that are longer than 4 m, please always use hoses that
correspond to the upper value of the scale.
In order to avoid pressure loss, cut the spiral stepped hose adapter
at the relevant points for each hose.
Avoid unnecessary corners and bends which contribute to further
pressure loss.
1''
1 ¼''
1 ½''
¾“
The filter system with integrated UVC must be running permanently,
24 hours a day.
The UVC lamp must be replaced after 8,000 hours of operation in
order to ensure that the Filtoclear UVC continues to operate with
optimum effectiveness.
The filter system must be cleaned regularly.
Pressure loss due to height difference
The selection table allows for a maximum height difference of 1 m
between the surface of the water and the highest point of the
filtering system. If the height difference is greater than 1 m, you
should use a correspondingly more powerful pump.
Filtoclear 3.000 Filtoclear 6.000 Filtoclear 11.000
Aquamax 2.000 1.500 l 750 l - - - -
Aquamax 3.500 2.500 l 1.250 l 3.000 l 1.500 l - -
Aquamax 5.500 3.000 l 1.500 l 4.000 l 2.000 l 6.000 l 3.000 l
Aquamax 10.000 - - 6.000 l 3.000 l 8.000 l 4.000 l
Aquamax15.000 - - - - 11.000 l 5.500 l
Slight pollution of pond
without fish population
Heavy pollution of pond
with fish population
