OAV P30 - Page 35

P30
ASSEM01-3.1
ITEM PART NO NOTE
1 SS100400 H
2 NH101700 H
207077 R
207151 OPT.
4 SR100500 H
5 206332 R
6 207352 R
7 WF102030 H
8 WS100000 H
9 SJ069300
10 206354
11 SS162000
12 NL162400
13 205016
14 NH162400
15 WF061620 H
16 SJ069300 H
17 200881
18 WF132225
19 SR089300
20 WS080000
21 206437
22 206372
23 SS060200
24 200957
25 NH121900
26 206458 X7
27 NH061000 H
LM206305 Metric
LM206307
M/B (OPT.)
PARTS NAME SIZE Q`TY
Set Screw
M10*20
4
Hex Nut
M10
4
3
Left Ext. Plate
S
1
Left Ext. Plate
OPT.
1
Cap Screw
M10*25
4
Table 1
Ext. Plate
SMALL
1
Washer
M10*ψ20
4
Lock Washer
M10
4
Button Head Screw
M6*12
4
Table Insert 1
Set Screw
M16*100
4
Lock Nut
M16
4
Washer 8
Hex Nut
M16
4
Washer
M6*φ16
4
Button Head Screw
M6*12
3
Screw
M12×1.75p×115L
4
Washer
M13×22
4
Cap Screw
M8×16
1
Lock Washer
M8
1
Measuring Rule Rail 1
Setscrew
M6×10
1
Ring Stop
M6
1
Ruler
End Washer 1
Round Rail 1
28
1
Hex Nut
M12
8
Ruler 1
Hex Nut
